hot recommended filling machine price machine factory for industrial production

Enterprise Strength

With a focus on customers, EcoPura Water Treatment Equipment & Bottling Machine strives to meet their needs and provide one-stop professional and quality services wholeheartedly.

Company Advantages
1. EcoPura mineral water bottling plant manufacturer has some advantages that other products are incomparable with, such as lasting performance and relatively long service life.
2. Strict quality inspection procedures throughout the entire production process, must have excellent quality and performance.
3. EcoPura is committed to modern design style with outstanding value for money and without ignoring the quality of its traditional craftsmanship.
4. Quality is always the highlight point for Shenzhen EcoPura Water Equipment Co.,Ltd.

Product Detail

ECOPURA 5gallon bottle washing filling capping machine HSG600 with capacity 600bph.
A real Hygiene filling solution for your recycling use 5Gallon bottled water business with SIEMENS PLC Control and touch Screen control. All parts that come to contact with water are manufactured in Stainless steel 304 or 316L ,Equipped S.S304 Chemical tank for multistage rinsing

EcoPura machine filling machine price factory for industrial production-1

EcoPura machine filling machine price factory for industrial production-2

Bottles Sterilizing & Washing

Exclude the brusher pre-washing process for cleaning bottles inside & outside part, the pre-washed 5gallon bottles feed into the 3-in-1 washing filling capping unit which Designed Multistage high-pressure inner washing Process include Hot Alkaline washing, disinfection water washing, Dripping ,Ozonated pure water cleaning for ensuring the recycled bottles 100% clean & health, the washing system is controlled by pumping though cleaning tank and the ejecting nozzles on the bottle carrier to spraying the inner wall of the bottles by high pressure water, after finishing the washing process, the bottles will discharge though reverse turn-over mechanize and transported to the filling Part for full filling as designated volume and finally capping, discharge out the 3-in-1 by conveyor to next step

Caps Loading & washing

The Caps elevator doses the caps into the caps unscrambler then delivery through caps chute to enter into caps washing tunnel, finished clean caps feed following the chute transferring to capping position on capping machine .Design for online 5Gallon caps cleaning & Sterilizing by multistage washing process -detergent washing & purified water washing,

EcoPura machine filling machine price factory for industrial production-3

EcoPura machine filling machine price factory for industrial production-4

Rotary Filling & Capping

Clean bottles are discharged out of the rinse by conveyor to feed the filler. After entering the filler, bottles are retained by bottom supporting plates, which are actuated by bottle supporting mechanism to raise them to engage with filling valves. Filling valves are opened by bottle presence signals. After finishing filling, valves are closed by valve closing mechanism to further stop venting to complete the filling process.

Product Solution

A turnkey solution for 5Gallon bottling line

♦ 1.Automatic bottle decapper
♦ 2.Automatic inside & outside brusher washer
♦ 3.Automatic bottle feeder -Multistage high-pressure washing unit
♦ 4.Linear or Rotary filler & capper
♦ 5.Automatic Capsules Labeling shrinking
♦ 6.Light Inspection
♦ 7.Thin film (bag) Packing
♦ 8.Palletizer

Company Features
1. As a renowned manufacturer, Shenzhen EcoPura Water Equipment Co.,Ltd gradually takes superiority in developing and manufacturing mineral water bottling plant manufacturer in the domestic market.
2. We have our own advanced manufacturing facilities. This enables us to closely monitor every stage of the production process so that we can ensure the highest standard of quality.
3. In order to meet needs of customers, EcoPura also supplies the best service for customers except offered filling machine price with high performance. Please contact us! To create a relatively unified bottle filling machine price company is our purpose. Please contact us!

Product Description

2019 Hot Sell Automatic Small PET Bottle Mineral/Pure Water Bottling Filling Machine Price

1.water production line
2.Bottle washing machine
3.Bottle filling machine
4.Bottle capping machine

2000-36000BPH automatic bottled mineral water filling machine integrates washing , filling and capping into one unit, it can be used for filling production of different kinds of liquid. such as pure water ,mineral water ,soda water etc .

Model	CGF14125	CGF16166	CGF24246	CGF323210	CGF404012
washing, filling and capping heads	14-12-5	16-16-6	24-24-6	32-32-10	40-40-12
Production capacity (b/h)	4000-5000	7000-8000	8000-12000	12000-15000	16000-20000
suitable bottle specification	φ=50-110=170 330-2250ml
Washing pressure(kg/cm 2 )	2-3
Motor power(kw)	2.2kw	3kw	5.5kw	7.5kw	11kw
Overall dimensions(mm)	2600×1920×2550	3100×23002800	3800×2800×2900	4600×2800×2900	5450×3300×2900
Weight (kg)	3000	4000	6000	8000	9500

Photo Display

2019 Hot Sell Automatic Small PET Bottle Mineral/Pure Water Bottling Filling Machine Price
Production Line

Water treatment system

2019 Hot Sell Automatic Small PET Bottle Mineral/Pure Water Bottling Filling Machine Price

3 in 1 Filling machine

Sleeve labeling machine

Shrink packing machine

Main Parameter

NO.	ITEM	BRAND
1	Main electronic parts	SIEMENS
2	Electric protection switch	SIEMENS
3	Circuit breaker	SIEMENS
4	PLC	MITSUBISHI
5	Touch screen	SIEMENS
6	Transducer	MITSUBISHI
7	Photoelectricity switch	SIEMENS
8	Pneumatic element	FESTO

Featured Parts

2019 Hot Sell Automatic Small PET Bottle Mineral/Pure Water Bottling Filling Machine Price

Packaging & Shipment

2019 Hot Sell Automatic Small PET Bottle Mineral/Pure Water Bottling Filling Machine Price

Exhibition In Colombia

Welcome to visit U TECH MACHINE Company

FAQ

1. What about your baling machine quality?
Our factory has more than 10 years experience in mechanical processing; all our machines already get ISO9001, SGS certificate, CE certificate; already exported into many countries and areas; already got customer’s good reputation.
2. What about your baling machine price?
Anytime we will make quality as factory life, no matter price is good or not for us. Quality is first, on the top quality basis, Sure you will get reasonable and satisfied price!
3. How can you ensure the machine’s quality after we put the order?
Before the delivery, we will send you machine’s pictures and videos, or you can come to us to have the quality checking by yourself, or by the third party inspection organization contacted by your side.

4. To know more information about our company

<<Click Here to Back Home>>

h******s

Shenzhen EcoPura Water Equipment Co.,Ltd Constantly upgrade and renew production equipment and production lines, and explore technologies and processes to ensure that the overall quality of mineral water bottling plant manufacturer produced is more reliable.

d******k

Shenzhen EcoPura Water Equipment Co.,Ltd Standardized production is carried out in strict accordance with national standards, and the products are strictly tested with almost harsh quality control standards and inspection methods to ensure that the produced filling machine price are qualified products with reliable quality.

x******s

The company has strong strength and strict management. It not only has a standardized production workshop, but also has established a perfect quality management system. From the selection of raw materials to the delivery of finished products, the quality is strictly controlled in every link to ensure the excellent quality of mineral water bottling plant manufacturer.

m******h

The filling machine price we produce is fine in workmanship, reasonable in design, excellent in performance and stable in quality, and is a trustworthy high-quality product.

h******i

bottle filling machine price The design is scientific and reasonable, the materials are exquisite, the workmanship is fine, durable, and the service life is long. It is a product of high quality and extraordinary quality.

s******u

Many customers are satisfied with the high quality of this product. The product is sealed and welded exquisitely
