high quality juice filling machine juice more buying choices for distribution

Product Comparison

EcoPura Water Treatment Equipment & Bottling Machine has great production capability and excellent technology. We also have comprehensive production and quality inspection equipment. water treatment equipment has fine workmanship, high quality, reasonable price, good appearance, and great practicality.water treatment equipment is more competitive than other products in the same category, as shown in the following aspects.

Company Advantages
1. The tests for EcoPura [tea filling machine have been strictly conducted. These tests include vibration and shock testing, noise testing, thermal shock testing, fatigue testing, etc.
2. Featuring tea filling machine, juice filling machine is recognized by customers.
3. tea filling machine has no pollution to environment which is more eco-friendly.
4. The product is able to achieve optimal production or increase productivity by reasonably allocating the resources of workers and equipment.

Product Detail

ECOPURA 3-in-1 PET 0.3L-1.5L RHSG-series Hot-fill monobloc equipped with electronic filler nozzles designated for filling hot beverages such as Juice ,tea,pulp beverages or those liquid mixed particles

EcoPura juice juice filling machine more buying choices for distribution-1

Product Specification

Model	Bottle Spec	Capacity Cal@500ML	Power	PLC & HMI
DHSG16-16-12-6	0.33L-1.5L Height:150-330mm Dia: 50-115mm	3000-3500bph	1.8kw	SIEMENS
DHSG24-24-16-6		4000-5000bph	2.2kw
DHSG24-24-18-8		5000-6000bph	2.2kw
DHSG24-24-8		8000-9000bph	3.0kw
DHSG32-32-32-12		10000-12000bph	5.5kw
DHSG38-38-38-14		12000-15000bph	7.5kw
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

EcoPura juice juice filling machine more buying choices for distribution-2

High quality & Strict Hygiene

Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination. The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

EcoPura juice juice filling machine more buying choices for distribution-3

EcoPura juice juice filling machine more buying choices for distribution-4

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene.Neck-handling grippers position the PET container beneath the filling valve. Once the container has been centred, the filling process starts: Thereby, the Filling valve is opened and the product flows into the bottle with infinitely variable speed. Once the required fill volume has been reached, the flow meter provides a signal to the filling valve. The valve is now closed and the filling process completed. Dripping of the filling valve is prevented by a sieve in the product discharge. Microbiological safety by filling in a multi-chamber mode and separate return gas channel Precise determination of fill quantity via inductive flow meter Recirculation channel for heat retention of the product Perfect flow characteristics through two filling speeds Cleaning in a closed system using automatically positioned CIP cups

Capping Part

The capper is most precise part ensuring the machine to run credibility and product quality.The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish. As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutch ends the capping process. All main parts made of stainless steel AISI304 Pick station with adjustable height Torque and spring force of the capping head are adjustable Flushable cap retainer Motorised height adjustment of the capper top part with bottle selection feature

EcoPura juice juice filling machine more buying choices for distribution-5

EcoPura juice juice filling machine more buying choices for distribution-6

Caps online Sterilization

ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

Company Features
1. Until now, Shenzhen EcoPura Water Equipment Co.,Ltd has become one of the largest manufacturer for juice filling machine .
2. Our company has responsible directors and managers. They possess strong attention to detail, work tightly with all colleagues, staffs, workers, and suppliers for delivering the highest quality products and services.
3. Based on the idea of juice bottling machine , EcoPura has always been standing at the strategic height to push forward implementation of the plans. Ask online! Shenzhen EcoPura Water Equipment Co.,Ltd will adhere to new product and new technology research and development. Ask online! To provide the superb juice filling equipment and service experiences for our users is Shenzhen EcoPura Water Equipment Co.,Ltd's vision. Ask online! Shenzhen EcoPura Water Equipment Co.,Ltd makes a endeavor to bring better juice filling machine and better service to customers. Ask online!

u******p

EcoPura juice filling equipment has passed through a comprehensive range of quality control tests to make sure it is totally free of hazardous substances.

f******n

The fabric of EcoPura juice filling machine is carefully chosen by our designers on the basis of fashion trends, quality, performance, and suitability.

z******f

The entire production process of EcoPura juice filling machine is tightly controlled, from selecting the finest fabrics to processing them into finished clothing.

q******q

The fabrics of EcoPura juice filling machine has passed through the stretch test and it is proven to be qualified for proper elasticity.

z******z

EcoPura juice filling equipment has been tested on dimensional stability, performance(abrasion or pilling), and colorfastness to meet the regulatory requirements of the apparel industry.

n******m

This product can last for decades. Its joints combine the use of joinery, glue, and screws, which are tightly combined with each other.
