ISO9001 certified wine bottling equipment filling trader for industrial production

Product Details

With the pursuit of perfection, EcoPura Water Treatment Equipment & Bottling Machine exerts ourselves for well-organized production and high-quality bottling line.EcoPura Water Treatment Equipment & Bottling Machine pays great attention to integrity and business reputation. We strictly control the quality and production cost in the production. All these guarantee bottling line to be quality-reliable and price-favorable.

Company Advantages
1. The manufacturinhg process of EcoPura wine bottling equipment has been optimized to ensure that key parameters can be achieved, such as function, physical space, standby, maintenance, capital, and operating costs, environmental impacts, and more.
2. The product features strong resistance to corrosion. Non-corrosive materials have been used in its structure to enhance its capacity to withstand rust or acidity liquid.
3. The market's response to the product is positive, which means that the product will be more used in the market.
4. The product is reasonably priced and is favored by many customers and will be widely used in the market.

Product Detail

ECOPURA 3-in-1 Glass 0.3L-1.5L HSG-G series monobloc equipped with overflow filler nozzles designated for filling wine or Sparking wine

EcoPura ISO9001 certified wine bottling equipment trader for industrial production-1

Product Specification

Model	Bottle Spec	Capacity Cal@500ML	Power	PLC & HMI
HSG8-8-3G	0.33L-1.5L Height:150-330mm Dia: 50-115mm	5000-3000bph	1.5kw	SIEMENS
HSG16-12-6G		3000-4500bph	1.8kw
HSG24-16-6G		5000-6000bph	2.2kw
HSG24-18-8G		7000-8000bph	2.2kw
HSG24-24-8G		10000-12000bph	3.0kw
HSG32-32-12G		15000-18000bph	5.5kw
HSG38-38-14G		18000-20000bph	7.5kw
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

EcoPura ISO9001 certified wine bottling equipment trader for industrial production-2

High quality & Strict Hygiene

Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

EcoPura ISO9001 certified wine bottling equipment trader for industrial production-3

EcoPura ISO9001 certified wine bottling equipment trader for industrial production-4

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene. The lift cylinder presses the bottle on to the filling valve where it is pre-evacuated several times. With non-carbonated beverages, the filling valve opens due to a movement of the control cylinder. With carbonated beverages, the bottle is pressurised and the valve opens as soon as the bottle and the ring bowl have the same pressure. At both of the filling processes, the liquid runs through a spreader along the bottle wall. The valve closes as soon as the bottle is entirely filled. The correction channel opens and the excessive fill quantity is displaced from the bottle to the end of the vent tube. With carbonated beverages, a snifting phase is performed in order to reduce the pressure in the bottle head space. Non- carbonated beverages can be removed from the filling valve right after filling is completed.

Aluminum Roll-On Capping Part

After they have been sorted according to their positions in the sorter, the caps are fed to the capper via an open chute. A towing shoe positions the caps, which are then directly picked up by the bottle. If a cap is missing, a safety plunger prevents contact between the rollers and the bottle neck finish. Depending on the cap type, a “fixed” or a deep-drawing plunger is used for press-on and shaping. The thread is rolled out via moveable arms, and if necessary, the tamper-evident band is flanged. The lateral pressure can be easily readjusted with adjusting screws.

EcoPura ISO9001 certified wine bottling equipment trader for industrial production-5

EcoPura ISO9001 certified wine bottling equipment trader for industrial production-6

Caps online Sterilization

ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

Company Features
1. Shenzhen EcoPura Water Equipment Co.,Ltd has become the largest production base for wine bottling equipment in Pearl River Delta.
2. The basic requirement for EcoPura to maintain relies on the quality assurance of wine bottle filler .
3. It is the eternal tenet for Shenzhen EcoPura Water Equipment Co.,Ltd to pursue wine filter machine . Get price! Shenzhen EcoPura Water Equipment Co.,Ltd will set up a management mode that takes the customer's demand as the direction. Get price! Shenzhen EcoPura Water Equipment Co.,Ltd deeply believes that customers are the source of long-term development for an enterprise. Get price!
