ISO9001 certified beer bottling machine beer purchase online for importer

Company Advantages
1. EcoPura beer bottle filler is produced under the support of high techs. They are energy-saving technology, operate and control system, and fabrication technique of mechanical parts. The product can enhance the speed, accuracy, and efficiency of workers
2. Shenzhen EcoPura Water Equipment Co.,Ltd has gathered an experienced team with and strict management. The product is widely used for commercial applications
3. It has good stiffness and rigidity. Under the effect of applied forces for which it is designed, there is no deformation beyond the specified limits. The product is energy-saving, consuming little energy

Product Detail

ECOPURA 3-in-1 Glass 0.3L-1.0L HSG-B series monobloc equipped with overflow filler nozzles designated for filling wine or Sparking wine

EcoPura ISO9001 certified beer bottling machine purchase online for importer-1

Product Specification

Model

Bottle Spec

Capacity Cal@500ML

Power

PLC & HMI

HSG8-8-3G

0.33L-1.5L
Height:150-330mm
Dia: 50-115mm

2000-3000bph

1.5kw

SIEMENS

HSG16-12-6G

3000-4500bph

1.8kw

HSG24-16-6G

5000-6000bph

2.2kw

HSG24-18-8G

7000-8000bph

2.2kw

HSG24-24-8G

10000-12000bph

3.0kw

HSG32-32-12G

15000-18000bph

5.5kw

HSG38-38-14G

18000-20000bph

7.5kw

EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

EcoPura ISO9001 certified beer bottling machine purchase online for importer-2

High quality & Strict Hygiene

Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316. hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination. The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

EcoPura ISO9001 certified beer bottling machine purchase online for importer-3

EcoPura ISO9001 certified beer bottling machine purchase online for importer-4

Filling Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination
The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

Crown Cappe

Once the crown has been fed from the crown chute into the transfer segment, a magnet is used for the further guidance of the crown. A pushing notch is then used to position the crown on the ejection plunger of the capping head. The crowning head is lowered until the crown in the crowning throat is placed on the bottle. The bottle then holds it in place. Afterwards only the crowning throat continues to be lowered. In the first phase, only the force of the guiding springs has any effect on the crown.

EcoPura ISO9001 certified beer bottling machine purchase online for importer-5

EcoPura ISO9001 certified beer bottling machine purchase online for importer-6

Caps online Sterilization

ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

Company Features
1. After years of dedication to beer bottling machine production, Shenzhen EcoPura Water Equipment Co.,Ltd has already become an expert with competence in R&D and manufacture. We have dedicated teams. Representing creative possibility with grounded experience, they allow the company to provide state of the art product analysis, development, and manufacture.
2. Shenzhen EcoPura Water Equipment Co.,Ltd has the advantages of manufacturing beer bottle filling machine.
3. We have experienced designers and engineers. They have detailed knowledge of specific application requirements of the product, allowing the company to tailor products to needs. Shenzhen EcoPura Water Equipment Co.,Ltd aims to lead the commercial trend with innovative spirit and bring long-lasting value with high-quality products. Contact us!

v******i

From the materials to designs, EcoPura beer bottle filling machine is totally guaranteed by our professional expertise. It has a compact design, occupying less space

n******x

EcoPura beer bottle filling machine is designed with a trendy and aesthetically-appealing look.

n******h

EcoPura beer bottle filling machine is designed with an innovative and attractive appearance. It has a compact design, occupying less space

n******a

EcoPura beer bottling machine is designed with an aesthetically-pleasing look that sets it apart from the ordinary. The product can greatly contribute to production efficiency

u******c

EcoPura beer bottle filler is manufactured as per the current industry standards. The product works very smoothly and causes less noise

r******j

beer bottle filler The design is scientific and reasonable, the structure is tight and compact, the practicability is strong, the safety is high, it has the characteristics of anti-corrosion and wear resistance, strong self-cleaning ability, long service life, stable quality and high quality.
