high quality juice filling machine filling more buying choices for distribution

Enterprise Strength

EcoPura Water Treatment Equipment & Bottling Machine adopts advanced production and management technology to carry out organic production. We also maintain close partnerships with other well-known domestic companies. We are committed to providing customers with quality products and professional services.

Product Details

We are confident about the exquisite details of water treatment equipment.EcoPura Water Treatment Equipment & Bottling Machine has great production capability and excellent technology. We also have comprehensive production and quality inspection equipment. water treatment equipment has fine workmanship, high quality, reasonable price, good appearance, and great practicality.

Company Advantages
1. Developed by a professional R&D team, EcoPura juice filling machine price has ultra-sensitive and responsive surface. The team always strive to improve its screen touch technology so as to provide better writing and drawing experience.
2. Combining juice filling machine price with tea filling machine makes juice filling machine more applicable.
3. Shenzhen EcoPura Water Equipment Co.,Ltd focuses on building relationships and providing the best customer service possible.
4. We have good team focus on exporting high quality juice filling machine to the world.

Product Detail

ECOPURA 3-in-1 PET 0.3L-1.5L RHSG-series Hot-fill monobloc equipped with electronic filler nozzles designated for filling hot beverages such as Juice ,tea,pulp beverages or those liquid mixed particles

EcoPura high quality juice filling machine more buying choices for distribution-1

Product Specification

Model	Bottle Spec	Capacity Cal@500ML	Power	PLC & HMI
DHSG16-16-12-6	0.33L-1.5L Height:150-330mm Dia: 50-115mm	3000-3500bph	1.8kw	SIEMENS
DHSG24-24-16-6		4000-5000bph	2.2kw
DHSG24-24-18-8		5000-6000bph	2.2kw
DHSG24-24-8		8000-9000bph	3.0kw
DHSG32-32-32-12		10000-12000bph	5.5kw
DHSG38-38-38-14		12000-15000bph	7.5kw
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

EcoPura high quality juice filling machine more buying choices for distribution-2

High quality & Strict Hygiene

Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination. The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

EcoPura high quality juice filling machine more buying choices for distribution-3

EcoPura high quality juice filling machine more buying choices for distribution-4

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene.Neck-handling grippers position the PET container beneath the filling valve. Once the container has been centred, the filling process starts: Thereby, the Filling valve is opened and the product flows into the bottle with infinitely variable speed. Once the required fill volume has been reached, the flow meter provides a signal to the filling valve. The valve is now closed and the filling process completed. Dripping of the filling valve is prevented by a sieve in the product discharge. Microbiological safety by filling in a multi-chamber mode and separate return gas channel Precise determination of fill quantity via inductive flow meter Recirculation channel for heat retention of the product Perfect flow characteristics through two filling speeds Cleaning in a closed system using automatically positioned CIP cups

Capping Part

The capper is most precise part ensuring the machine to run credibility and product quality.The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish. As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutch ends the capping process. All main parts made of stainless steel AISI304 Pick station with adjustable height Torque and spring force of the capping head are adjustable Flushable cap retainer Motorised height adjustment of the capper top part with bottle selection feature

EcoPura high quality juice filling machine more buying choices for distribution-5

EcoPura high quality juice filling machine more buying choices for distribution-6

Caps online Sterilization

ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

Company Features
1. Shenzhen EcoPura Water Equipment Co.,Ltd is celebrated for its high performance juice filling machine in the field.
2. Its production capacity and technology level for juice bottling machine are the important signs of a Shenzhen EcoPura Water Equipment Co.,Ltd's competitiveness.
3. Our corporate culture is to be innovative. That is, to work outside the box, to reject mediocrity, and to never drift along. We are heading towards to become a truly sustainable enterprise. We will significantly reduce the negative impact on the environment, such as reducing wastes discharge and carbon footprint. Our goal is that we aim to improve our products and solutions through innovations and smart thinking – to create more value at a reduced ecological footprint. We conduct responsible sourcing practices. We endeavor to source our ingredients responsibly and sustainably with respect for local communities and the environment.

q******x

EcoPura juice bottling machine is developed for optimal performance. After many simulations, its illuminating parameters are close to the ideal value.

n******h

EcoPura tea filling machine not only meets domestic quality standards but also meets international quality and safety standards for LED lamps such as RoHS and CE.

b******z

EcoPura juice bottling machine is made of a heat-conducting material, and the thermal conductivity is improved, which ultimately helps to improve the heat dissipation rate.

i******k

EcoPura juice filling machine has been verified to meet various quality requirements. It has been tested to work properly under various conditions, even harsh conditions.

g******l

EcoPura tea filling machine has passed various quality tests. These tests include electrical strength tests, which improves it meet European electrical safety standards.

f******k

juice filling machine It is manufactured by the industry's advanced manufacturing technology and processing technology. It has strong corrosion resistance and impact resistance, is durable and has a long service life.
