high quality juice filling machine machine international market for distribution

Enterprise Strength

EcoPura Water Treatment Equipment & Bottling Machine keeps ourselves open to all feedback from customers with a sincere and modest attitude. We constantly strive for service excellence by improving our deficiencies according to their suggestions.

Company Advantages
1. The offered EcoPura juice filling machine price is produced using modern technology in conformance with the set industry standards.
2. juice filling machine 's design uses juice filling machine price concept.
3. By the technology of juice filling machine price , juice filling machine has achieved high performance especially in its tea filling machine.
4. Shenzhen EcoPura Water Equipment Co.,Ltd has taken advantage of various means to promote the competitiveness of its juice filling machine .
5. EcoPura has been a steady growth thanks to the high quality products and professional service.

Product Detail

ECOPURA 3-in-1 PET 0.3L-1.5L RHSG-series Hot-fill monobloc equipped with electronic filler nozzles designated for filling hot beverages such as Juice ,tea,pulp beverages or those liquid mixed particles

EcoPura high quality juice filling machine international market for distribution-1

Product Specification

Model	Bottle Spec	Capacity Cal@500ML	Power	PLC & HMI
DHSG16-16-12-6	0.33L-1.5L Height:150-330mm Dia: 50-115mm	3000-3500bph	1.8kw	SIEMENS
DHSG24-24-16-6		4000-5000bph	2.2kw
DHSG24-24-18-8		5000-6000bph	2.2kw
DHSG24-24-8		8000-9000bph	3.0kw
DHSG32-32-32-12		10000-12000bph	5.5kw
DHSG38-38-38-14		12000-15000bph	7.5kw
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

EcoPura high quality juice filling machine international market for distribution-2

High quality & Strict Hygiene

Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination. The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

EcoPura high quality juice filling machine international market for distribution-3

EcoPura high quality juice filling machine international market for distribution-4

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene.Neck-handling grippers position the PET container beneath the filling valve. Once the container has been centred, the filling process starts: Thereby, the Filling valve is opened and the product flows into the bottle with infinitely variable speed. Once the required fill volume has been reached, the flow meter provides a signal to the filling valve. The valve is now closed and the filling process completed. Dripping of the filling valve is prevented by a sieve in the product discharge. Microbiological safety by filling in a multi-chamber mode and separate return gas channel Precise determination of fill quantity via inductive flow meter Recirculation channel for heat retention of the product Perfect flow characteristics through two filling speeds Cleaning in a closed system using automatically positioned CIP cups

Capping Part

The capper is most precise part ensuring the machine to run credibility and product quality.The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish. As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutch ends the capping process. All main parts made of stainless steel AISI304 Pick station with adjustable height Torque and spring force of the capping head are adjustable Flushable cap retainer Motorised height adjustment of the capper top part with bottle selection feature

EcoPura high quality juice filling machine international market for distribution-5

EcoPura high quality juice filling machine international market for distribution-6

Caps online Sterilization

ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

Company Features
1. Shenzhen EcoPura Water Equipment Co.,Ltd provides one package service of juice filling machine price , including R&D, manufacturing, and supplying. We are recognized for our manufacturing capacity.
2. Applying the high technology is conducive to the efficient production of juice filling machine .
3. Developing EcoPura into a global brand in juice bottling machine industry is our pursuing goal. Get an offer! Corporate missions of tea filling machine demonstrate the Shenzhen EcoPura Water Equipment Co.,Ltd's fundamental purpose and justification. Get an offer! Our vision is to achieve a first-rate brand and become a competitive juice filling equipment company. Get an offer!

i******y

EcoPura juice bottling machine is under the real-time control of the R&D team. The team will carry out a routine sampling and analysis of the raw materials so as to acquire information necessary for the economic appraisal of ores and concentrates.

q******d

EcoPura juice filling machine price is produced under advanced equipment. It will be processed by fastness to washing tester, steamer and washer, as well as vacuum cleaning equipment designed for textile.

s******s

EcoPura juice filling equipment is under constant control in terms of health, safety, and environmental protection standards, as evidenced by the CE certificate issued.

x******n

The quality control of EcoPura juice bottling machine is conducted rigorously. It is tested in terms of its air circulation, surface treatment, as well as the most important part, thermal dissipation performance.

d******z

All EcoPura juice filling equipment are manufactured in compliance with rubber and plastic industry standards and are tested for quality conformance in the laboratory.

g******x

The product features stable performance. The proportions of the various raw materials are carefully mixed together to achieve consistent properties.
