juice bottling machine | Juice Filling Machine

Company Advantages
1. During the design stage of EcoPura juice bottling machine , many factors have been taken into considerations such as flexibility, cycle times, tolerances, size precision, etc. The product is equipped with air conveyor and frequency control
2. The benefits of this product have been proven over time. It is not only highly efficient in production, but also helps save labor costs. The operation of this product is controlled by microcomputer
3. The product is highly resistant to stains. It has been treated with soil release finishing agent during the production to enhance its stains handling capacity. The product features excellent purification technology
4. This product has excellent impact resistance. Its high compressibility and rebound resilience allow it to work under high-pressure mechanical movement. It can be configured in a straight line or in an L-shaped configuration

Product Detail

ECOPURA 3-in-1 PET 0.3L-1.5L RHSG-series Hot-fill monobloc equipped with electronic filler nozzles designated for filling hot beverages such as Juice ,tea,pulp beverages or those liquid mixed particles

EcoPura high quality juice bottling machine more buying choices for trader-1

Product Specification

Model	Bottle Spec	Capacity Cal@500ML	Power	PLC & HMI
DHSG16-16-12-6	0.33L-1.5L Height:150-330mm Dia: 50-115mm	3000-3500bph	1.8kw	SIEMENS
DHSG24-24-16-6		4000-5000bph	2.2kw
DHSG24-24-18-8		5000-6000bph	2.2kw
DHSG24-24-8		8000-9000bph	3.0kw
DHSG32-32-32-12		10000-12000bph	5.5kw
DHSG38-38-38-14		12000-15000bph	7.5kw
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

EcoPura high quality juice bottling machine more buying choices for trader-2

High quality & Strict Hygiene

Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination. The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

EcoPura high quality juice bottling machine more buying choices for trader-3

EcoPura high quality juice bottling machine more buying choices for trader-4

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene.Neck-handling grippers position the PET container beneath the filling valve. Once the container has been centred, the filling process starts: Thereby, the Filling valve is opened and the product flows into the bottle with infinitely variable speed. Once the required fill volume has been reached, the flow meter provides a signal to the filling valve. The valve is now closed and the filling process completed. Dripping of the filling valve is prevented by a sieve in the product discharge. Microbiological safety by filling in a multi-chamber mode and separate return gas channel Precise determination of fill quantity via inductive flow meter Recirculation channel for heat retention of the product Perfect flow characteristics through two filling speeds Cleaning in a closed system using automatically positioned CIP cups

Capping Part

The capper is most precise part ensuring the machine to run credibility and product quality.The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish. As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutch ends the capping process. All main parts made of stainless steel AISI304 Pick station with adjustable height Torque and spring force of the capping head are adjustable Flushable cap retainer Motorised height adjustment of the capper top part with bottle selection feature

EcoPura high quality juice bottling machine more buying choices for trader-5

EcoPura high quality juice bottling machine more buying choices for trader-6

Caps online Sterilization

ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

Company Features
1. Shenzhen EcoPura Water Equipment Co.,Ltd is the main developer and supplier of juice bottling machine . The technology capability of Shenzhen EcoPura Water Equipment Co.,Ltd is widely recognized by juice filling machine industry.
2. Shenzhen EcoPura Water Equipment Co.,Ltd strictly implements quality assurance standards, processes and controls.
3. Shenzhen EcoPura Water Equipment Co.,Ltd has strong technical force and first-class service in juice filling equipment industry. All our members are working hard to build the first brand of juice filling machine price . Check it!

q******u

EcoPura juice filling equipment is well designed. Its detailed design includes mechanical design, structural design, electrical control design, instrument panel design, etc.

r******y

The manufacture of EcoPura juice filling machine price includes the specific design of the polymer optical component, assembly, concept and prototype testing through to mass production with multiple injection molding processes, optoelectronic assembly, and packing.

w******t

Quality tests of EcoPura juice filling machine will be conducted rigorously complying with the requirements in the phone accessories industry. It has a series of quality tests including pressure test, high/low-temperature test, strength test, etc.

x******a

Before production, the materials and components of EcoPura juice filling machine price have to go through inspections. They must be verified by the QC team to ensure its maximum electrical safety.

i******x

EcoPura juice bottling machine is made with suitable materials. The designer determines the material according to the goods. For example, if the displayed goods are heavy, the better choice is wood/wire/plastic material.

n******q

This high-quality juice filling machine price is constructed with well-chosen materials and elaborate workmanship. It is a safe and eco-friendly product with high sturdiness and long-lasting durability. It is easy to assemble and disassemble. It sells well and enjoys wide acclaim in the domestic and foreign markets.
