standard juice filling machine filling international market for distribution

Product Details

EcoPura Water Treatment Equipment & Bottling Machine's bottling line has excellent performances by virtue of the following excellent details.EcoPura Water Treatment Equipment & Bottling Machine insists on the use of high-quality materials and advanced technology to manufacture bottling line. Besides, we strictly monitor and control the quality and cost in each production process. All this guarantees the product to have high quality and favorable price.

Product Comparison

water treatment equipment, manufactured based on high-quality materials and advanced technology, has reasonable structure, excellent performance, stable quality, and long-lasting durability. It is a reliable product which is widely recognized in the market.Compared with other same kind of products, water treatment equipment produced by EcoPura Water Treatment Equipment & Bottling Machine has the following advantages and features.

Company Advantages
1. EcoPura tea filling machine has gone through the following four kinds of tests: dielectric withstand/hipot test, isolation resistance test, leakage current test, etc.
2. Its quality can withstand the test of the third party.
3. All incoming materials are inspected to ensure they match the quality requirement.
4. Shenzhen EcoPura Water Equipment Co.,Ltd has gathered a group of outstanding management talents and technical talents for juice filling machine .
5. By cause of tea filling machine, our competence in juice filling machine industry has been increasing a lot.

Product Detail

ECOPURA 3-in-1 PET 0.3L-1.5L RHSG-series Hot-fill monobloc equipped with electronic filler nozzles designated for filling hot beverages such as Juice ,tea,pulp beverages or those liquid mixed particles

EcoPura filling juice filling machine international market for distribution-1

Product Specification

Model	Bottle Spec	Capacity Cal@500ML	Power	PLC & HMI
DHSG16-16-12-6	0.33L-1.5L Height:150-330mm Dia: 50-115mm	3000-3500bph	1.8kw	SIEMENS
DHSG24-24-16-6		4000-5000bph	2.2kw
DHSG24-24-18-8		5000-6000bph	2.2kw
DHSG24-24-8		8000-9000bph	3.0kw
DHSG32-32-32-12		10000-12000bph	5.5kw
DHSG38-38-38-14		12000-15000bph	7.5kw
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

EcoPura filling juice filling machine international market for distribution-2

High quality & Strict Hygiene

Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination. The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

EcoPura filling juice filling machine international market for distribution-3

EcoPura filling juice filling machine international market for distribution-4

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene.Neck-handling grippers position the PET container beneath the filling valve. Once the container has been centred, the filling process starts: Thereby, the Filling valve is opened and the product flows into the bottle with infinitely variable speed. Once the required fill volume has been reached, the flow meter provides a signal to the filling valve. The valve is now closed and the filling process completed. Dripping of the filling valve is prevented by a sieve in the product discharge. Microbiological safety by filling in a multi-chamber mode and separate return gas channel Precise determination of fill quantity via inductive flow meter Recirculation channel for heat retention of the product Perfect flow characteristics through two filling speeds Cleaning in a closed system using automatically positioned CIP cups

Capping Part

The capper is most precise part ensuring the machine to run credibility and product quality.The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish. As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutch ends the capping process. All main parts made of stainless steel AISI304 Pick station with adjustable height Torque and spring force of the capping head are adjustable Flushable cap retainer Motorised height adjustment of the capper top part with bottle selection feature

EcoPura filling juice filling machine international market for distribution-5

EcoPura filling juice filling machine international market for distribution-6

Caps online Sterilization

ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

Company Features
1. After years of solid development, Shenzhen EcoPura Water Equipment Co.,Ltd has become one of the backbone companies that specialize in the R&D and production of juice filling machine .
2. Shenzhen EcoPura Water Equipment Co.,Ltd has a lot of mature technologies and strong processing and manufacturing capabilities for juice bottling machine .
3. We build up a strong company culture of society charity while maintaining profitable growth in business. We regularly hold or take part in all kinds of donation projects or charity sells. We take steps to maintain sustainable development. We minimize energy consumption and lower production waste while thinking highly of environmental impacts. Providing innovative goods and services of the highest standards that surpasses customer expectations of quality, delivery, and productivity. Our mission is to continuously improve and provide our products and services in a safe, efficient and courteous manner consistent with good craftsmanship, professionalism.
