latest carbonated soft drinks filling machine filling factory for sale

Company Advantages
1. The materials used for EcoPura soda filling machine price have been tested. The testing procedures include tensile testing, toughness or brittleness testing, hardness testing, infiltrate testing and testing through radiations. It can be configured in a straight line or in an L-shaped configuration
2. Using this product helps reduce workers' workload and cut working time. It has been proved to be more efficient than workers' operations. Its parts are all made of CNC machines, which features high accuracy
3. This product has excellent performance and long service life. Made of stainless steel materials, the product has a smooth surface to resist dust and dirt
4. Since we have established a good quality management system to prevent any possible defects, the quality of the products is guaranteed. The product generates little noise during operation

Product Detail

ECOPURA 3-in-1 PET 0.3L-1.5L DHSG-series monobloc equipped with isobaric filler nozzles designated for filling carbonated beverages such as Cola, beer, carbonated water and other liquids etc

EcoPura filling carbonated soft drinks filling machine factory for sale-1

Product Specification

Model	Bottle Spec	Capacity Cal@500ML	Power	PLC & HMI
DHSG16-12-6	0.33L-1.5L Height:150-330mm Dia: 50-115mm	3000-3500bph	1.8kw	SIEMENS
DHSG24-16-6		4000-5000bph	2.2kw
DHSG24-18-8		5000-6000bph	2.2kw
DHSG24-24-8		8000-9000bph	3.0kw
DHSG32-32-12		10000-12000bph	5.5kw
DHSG38-38-14		12000-15000bph	7.5kw
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

EcoPura filling carbonated soft drinks filling machine factory for sale-2

High quality & Strict Hygiene

Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316. hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination. The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

EcoPura filling carbonated soft drinks filling machine factory for sale-3

EcoPura filling carbonated soft drinks filling machine factory for sale-4

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene.The PET container is first pressed on by the PET lifting unit and pressurised afterwards. Once the same pressure is in the ring bowl and the PET container, the filling valve will be opened and the filling process starts. The liquid is gently fed via a swirl insert into the bottle. Two different filling speeds guarantee optimum flow behaviour. A flow meter monitors the fed liquid quantity. Once the exact filling volume has been reached, the flow meter provides a signal and the valve closes electro pneumatically Maximum flexibility − Filling of non-carbonated and carbonated products on one system Maximum filling accuracy − Precise determination of fill quantity via inductive flow meter Gentle product treatment during filling − Low-foam and low-turbulence filling vias wirl insert in the valve Hygiene and stable filling processes − Separate gas channels for pressurization and snifting ECOPURA filling machines in their standard version are suitable for CIP and beverage mixer

Capping Part

The capper is most precise part ensuring the machine to run credibility and product quality. The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish. As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutch ends the capping process. All main parts made of stainless steel AISI304 Pick station with adjustable height Torque and spring force of the capping head are adjustable Flushable cap retainer Motorised height adjustment of the capper top part with bottle selection feature

EcoPura filling carbonated soft drinks filling machine factory for sale-5

EcoPura filling carbonated soft drinks filling machine factory for sale-6

Caps online Sterilization

ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

Company Features
1. Shenzhen EcoPura Water Equipment Co.,Ltd is one of the few professional carbonated soft drinks filling machine supplier with independent R&D capabilities. We have a team specializing in product development. Their expertise enhances the planning of product optimization and process design. They effectively coordinate and implement our production.
2. Our products have been widely used in various fields in different countries and won market praise. They are mainly Germany, America, Canada, and other countries.
3. We have set up a professional sales team. With years of rich experience in the market, they are able to promote our business to grow and help us achieve business goals. We uphold a corporate culture of collaboration. We encourage employees to work together and deliver more business success through shared goals of mutual support.

o******j

EcoPura soda filling machine price is under the real-time control of the R&D team. The team will carry out a routine sampling and analysis of the raw materials so as to acquire information necessary for the economic appraisal of ores and concentrates.

y******n

EcoPura soda filling machine price is produced under advanced equipment. It will be processed by fastness to washing tester, steamer and washer, as well as vacuum cleaning equipment designed for textile.

s******b

EcoPura soda filling machine price is under constant control in terms of health, safety, and environmental protection standards, as evidenced by the CE certificate issued.

k******b

The quality control of EcoPura soda filling machine price is conducted rigorously. It is tested in terms of its air circulation, surface treatment, as well as the most important part, thermal dissipation performance.

h******u

All EcoPura soda filling machine price are manufactured in compliance with rubber and plastic industry standards and are tested for quality conformance in the laboratory.

n******j

The product features stable performance. The proportions of the various raw materials are carefully mixed together to achieve consistent properties.
