factory directly supply bottle labeler for sale shrink international market for sale

Product Comparison

Under the guidance of market, EcoPura Water Treatment Equipment & Bottling Machine constantly strives for innovation. bottle filling machine has reliable quality, stable performance, good design, and great practicality.Compared with other products in the same industry, EcoPura Water Treatment Equipment & Bottling Machine's bottle filling machine has the following characteristics.

Product Details

EcoPura Water Treatment Equipment & Bottling Machine's bottling line is exquisite in details.Well-chosen in material, fine in workmanship, excellent in quality and favorable in price, EcoPura Water Treatment Equipment & Bottling Machine's bottling line is highly competitive in the domestic and foreign markets.

Company Advantages
1. EcoPura auto label machine is designed in accordance with the industrial conditions as well as precise demands of the customers.
2. The product is guaranteed to be always at its best quality by our stringent quality management system.
3. Shenzhen EcoPura Water Equipment Co.,Ltd has a good operation system of production and quality control.
4. Shenzhen EcoPura Water Equipment Co.,Ltd has already regarded the international bottle labeler for sale market as a target for future development.

Product Detail

Double Head Sleeve Labeller

EcoPura 's double head sleeve labeler is the fruit of considering the potential for high demand of hygiene and eye catching is key to influencing the consumer purchasing decision and ensuring a significant impact on your product's success, double head sleeve labeler provide both labeling for container 's Cap and body The shrink sleeve labels are applied with a cling-fit to the contours of a container using thermal energy. This makes it possible to achieve all-round decoration whatever the shape of the container, the label sleeve can function as an effective seal and can also serve as a light barrier to protect the liquid.

EcoPura factory directly supply bottle labeler for sale international market for sale-1

Product Parameter

Model	EcoSL100D	EcoSL150D	EcoSL250D	EcoSL400D
Capacity	100b/min	150b/min	250b/min	400b/min
Label Height	＜250mm	＜250mm	＜250mm	＜250mm
Label Material	PVC, PET, OPS, PE, R-PET, PLA, PP
Label Thickness	Ranging from 15um to 130um
Containers Spec	Suitable for bottle size up to 2Liters with dia ranging from 50-100mm
Power	3kw	3kw	3kw	3kw

The key components

Double Sleeve applicator

Sleeve positioning

♦Sleeve lowered by a brush system

Double Sleeve supply unit

♦Two label film reel holders

Method of operation

♦ The infeed worm spaces the incoming containers to the pitch.
♦ The flat sleeve film is unwound from the reel in the sleeve supply unit.
♦ The deflection rollers in the sleeve supply unit function as a buffer.
♦ The feed rollers convey the sleeve film from the sleeve supply unit to the sleeve applicator.
♦ The opening mandrel opens the flat sleeve film.
♦ The opened sleeve is precisely cut to the desired length by a servo-controlled cutting unit.
♦ Two servo-controlled rollers accelerate the sleeve and apply it over the container.
♦ The downstream brush system ensures that the label is precisely fitted.

Shrink steaming tunnel: construction

♦ Container infeed
♦ Temperature gauge
♦ Door
♦ Steam pressure adjustment
♦ Shut-off valve for extraction system
♦ Steam extraction
♦ Container discharge

Shrink steaming tunnel: method of operation

♦ The containers with sleeves applied to them are fed through the steaming tunnel.
♦ The steam pressure adjustment facility and shut-off valve for the extraction system enable the required temperature in each segment of the tunnel to be set.
♦ The nozzle bars supply the steam to the sleeve from the bottom upwards.
♦ The sleeve shrinks under the impact of the heat and adapts to the shape of the container.
♦ The finished, sleeved container leaves the steaming tunnel.

Company Features
1. Shenzhen EcoPura Water Equipment Co.,Ltd is an evolving, efficient bottle labeler for sale manufacture with a collaborative environment.
2. We have experienced product management professionals. They have exceptional abilities in problem analyzing and solving with regard to product development, design, and production.
3. From the strict control of production technology, to advanced product customization services, Shenzhen EcoPura Water Equipment Co.,Ltd is committed to satisfy all its costumer. Inquiry! What we aim to do is that we devote ourselves into developing bottle labeler machine with highest quality and favored price wholeheartedly. Inquiry! In line with the principle of bottle labeler , EcoPura have gradually expanded the business. Inquiry!

p******w

The raw materials of EcoPura auto label machine is extremely strict selection.

o******o

EcoPura bottle labeler machine has a wide selection of high-quality materials.

j******c

EcoPura bottle labeler for sale is precisely designed using premium quality raw material and leading-edge technology.

z******f

The raw materials of EcoPura bottle labeler machine are sourced from the reputed vendors of the market.

j******f

The raw materials EcoPura bottle labeler for sale uses is selected by professional experts.

x******q

The product is exceptional in terms of durability and requires the least maintenance.
