EcoPura Water Treatment Equipment & Bottling Machine has the ability to meet different needs. bottling line is available in multiple types and specifications. The quality is reliable and the price is reasonable.After being improved greatly, EcoPura Water Treatment Equipment & Bottling Machine's bottling line is more advantageous in the following aspects.

Enterprise Strength

EcoPura Water Treatment Equipment & Bottling Machine has been unanimously recognized by customers for high cost performance, standardized market operation and good after-sales service.

Company Advantages
1. The purifying system of EcoPura water bottle moulding machine has been built using standardized 'building block' methods, allowing for quick delivery and installation.
2. The product runs safely and stably under low voltage. It has passed the low voltage test which proofs it can work and regulate to make itself adapt to the low-voltage power supply.
3. Under the backdrop of many manufacturers having required increased productivity, the product has been widely adopted in many industries.

Product Detail

9600-12000bph Servo blow molding machine EPC-6E EPC-9E

Over the years, EcoPura continuously optimized our design and technology innovation, we launched our latest blower EPC-6E ,9E, high speed blow molding machine with fully servo motor drive, can reach stable capacity of 9600bph-12000bph with highly intelligent, simply operate, energy saving, fast changeovers and outstanding performance. Adopts Siemens PLC & Touch screen which has perfect monitoring settings, fault display, automatic calculation report, memory storage functions etc to ensure the blower production situation under control at all times. All Servo control main drive, preforms division, mould clamping and stretching;all parameters can be settled on the PLC. The complex process is completed by digitalization which is safer, faster and more accurate with high flexibility.In addition, EPC-6E Blower has a patent design for cooling device which ensures the preforms heating head temperature cooling down after bottles coming out. There is a cooling water channel under the heating unit. When preforms are heating, the cooling water channel is used to block the heat of the lamp tube. Also there is a cooling air system under the cooling water channel to cool the bottle mouth and protect the tooth mouth from distortion. EcoPura unique innovative linear design structure with high blowing speed, sustainable 24-hour production, independent blowing valve group reduce production energy consumption!EPC-6E,9E Blower mainly used for blowing Water/CSD/Juice beverage bottle, Oil bottle ,condiment bottle ,cosmetic bottle and other packaging containers

EcoPura epc9e blow molding companies trade partner for b2b-1

EcoPura epc9e blow molding companies trade partner for b2b-2

EcoPura epc9e blow molding companies trade partner for b2b-3

EcoPura epc9e blow molding companies trade partner for b2b-4

EcoPura epc9e blow molding companies trade partner for b2b-5

Product Parameter

Model	EPC-6EL	EPC-9EL
Mold Cavities	6	9
Speed	9600bph	12000bph
Bottle Size	Up to 0.75L	Up to 0.75L
Bottle Height	＜245 mm	＜245 mm
Bottle Neck	Φ18-Φ38 mm	Φ18-Φ38 mm
Bottle Body Diameter	Φ68 mm	Φ68mm
Working Pressure	7-9kg/cm2	7-9kg/cm2
Low Pressure Air Consumption	2000L/min	2000L/min
Blowing Air Pressure	25-35kg/cm2	25-35kg/cm2
High Pressure Air Consumption	6000L/min	8000L/min
Heating lamp	48pcs	72pcs
Installation Power	96kw	110kw
Practical Power	30-50kw	40-60kw
Machine Size	L4.5mW2.2mH2.3m	L5.8mW2.2mH2.4m
Weight	7500kgs	9500kgs

Product Advantages

♦ Servo Control all process
♦ Electrical components are World famous brand: FESTO, Schneider, Omron etc
♦ Visibility, maintainability, standardized components, Safety
♦ A Scrap rate of under 0.1%
♦ Up to 99% production efficiency
♦ Changeovers in less than 30mins
♦ Oven electrical consumption cut by up to 25%-30%
♦ Compressed air saving up to 20%-25%

Company Features
1. Having been involved in the industry of blow molding companies for many years, Shenzhen EcoPura Water Equipment Co.,Ltd develops rapidly.
2. Shenzhen EcoPura Water Equipment Co.,Ltd has an well-recognized custom blow molding specialist team.
3. Shenzhen EcoPura Water Equipment Co.,Ltd respects customer’s culture, pays attention to customer’s experience. Call! water bottle moulding machine is just one example of our commitment to product innovation. Call! Enterprise culture is highly significant to Shenzhen EcoPura Water Equipment Co.,Ltd for long-term development. Call! Adhering to the concept of blow moulding and implementing moulding machine help EcoPura achieve sustainable growth. Call!

u******e

The quality of EcoPura blow molding companies complies with the performance requirements for residential and nonresidential furniture. It has passed the aging, impact, vibration, stain, and structural stability testings.

s******b

In terms of surface finishes, EcoPura blow moulding provide all possible options. The surface treatment is available in a variety of ways.

r******s

The manufacturing process of EcoPura blow moulding is very complex. As long as a detail is missed in the structure, the mattress may not provide the required level of comfort.

b******u

EcoPura blow moulding is carefully created. Its design sets out with a desired aesthetic in mind. The function is catered to as a secondary factor.

n******n

EcoPura blow molding companies must undergo a quality control process. This includes checking the color fastness of the fabric, color correction, and the security of the attachment.

g******x

This product does not have the electric leakage problems. It is made of quality insulation materials and embedded with an insulation protection system to prevent electric danger.
