low moq Bottle Labeling Machine double trade partner for wholesale

Product Comparison

water treatment equipment has the following advantages: well-chosen materials, reasonable design, stable performance, excellent quality, and affordable price. Such a product is up to the market demand.After being improved greatly, EcoPura Water Treatment Equipment & Bottling Machine's water treatment equipment is more advantageous in the following aspects.

Enterprise Strength

EcoPura Water Treatment Equipment & Bottling Machine has always been insisting on providing quality services for customers.

Company Advantages
1. Bottle Labeling Machine also has aesthetic advantages.
2. The product can work with high accuracy. Its distinguished self-diagnostic feature can make sure that every motion is of high accuracy.
3. Storage assurance is also a way for EcoPura to ensure the fast delivery time.

Product Detail

Double Head Sleeve Labeller

EcoPura 's double head sleeve labeler is the fruit of considering the potential for high demand of hygiene and eye catching is key to influencing the consumer purchasing decision and ensuring a significant impact on your product's success, double head sleeve labeler provide both labeling for container 's Cap and body The shrink sleeve labels are applied with a cling-fit to the contours of a container using thermal energy. This makes it possible to achieve all-round decoration whatever the shape of the container, the label sleeve can function as an effective seal and can also serve as a light barrier to protect the liquid.

EcoPura double Bottle Labeling Machine trade partner for wholesale-1

Product Parameter

Model	EcoSL100D	EcoSL150D	EcoSL250D	EcoSL400D
Capacity	100b/min	150b/min	250b/min	400b/min
Label Height	＜250mm	＜250mm	＜250mm	＜250mm
Label Material	PVC, PET, OPS, PE, R-PET, PLA, PP
Label Thickness	Ranging from 15um to 130um
Containers Spec	Suitable for bottle size up to 2Liters with dia ranging from 50-100mm
Power	3kw	3kw	3kw	3kw

The key components

Double Sleeve applicator

Sleeve positioning

♦Sleeve lowered by a brush system

Double Sleeve supply unit

♦Two label film reel holders

Method of operation

♦ The infeed worm spaces the incoming containers to the pitch.
♦ The flat sleeve film is unwound from the reel in the sleeve supply unit.
♦ The deflection rollers in the sleeve supply unit function as a buffer.
♦ The feed rollers convey the sleeve film from the sleeve supply unit to the sleeve applicator.
♦ The opening mandrel opens the flat sleeve film.
♦ The opened sleeve is precisely cut to the desired length by a servo-controlled cutting unit.
♦ Two servo-controlled rollers accelerate the sleeve and apply it over the container.
♦ The downstream brush system ensures that the label is precisely fitted.

Shrink steaming tunnel: construction

♦ Container infeed
♦ Temperature gauge
♦ Door
♦ Steam pressure adjustment
♦ Shut-off valve for extraction system
♦ Steam extraction
♦ Container discharge

Shrink steaming tunnel: method of operation

♦ The containers with sleeves applied to them are fed through the steaming tunnel.
♦ The steam pressure adjustment facility and shut-off valve for the extraction system enable the required temperature in each segment of the tunnel to be set.
♦ The nozzle bars supply the steam to the sleeve from the bottom upwards.
♦ The sleeve shrinks under the impact of the heat and adapts to the shape of the container.
♦ The finished, sleeved container leaves the steaming tunnel.

Company Features
1. The wide application of auto label machine makes EcoPura to win more recognition.
2. The production of Bottle Labeling Machine is completed in advanced machines.
3. Being focused on a healthier and more productive world, we will keep socially and environmentally conscious in the future operation. To uphold green production, beyond reducing waste and properly utilizing resources, we are also seeking a more environmental-friendly packaging way. For example, we hope to reuse cardboard boxes or turn the discarded papers into environmentally friendly packaging materials. We don't strive to be the largest seller in the industry. Our goals are simple: to sell the best products at the lowest cost and provide industry-leading customer service.

g******t

With its appealing design, EcoPura auto label machine will attract more attention than before. It is proudly manufactured by Unique Group with the scientific and technological innovation accumulated over the past 30 years

d******d

During the production process, the design stage of EcoPura Bottle Labeling Machine is viewed as an important part. Its painting color can be customized to satisfy the needs of different customers

b******t

The production process of EcoPura auto label machine has been standardized by using the advanced technology. It has an anti-abrasion spraying coat, which improves its long term abrasion performance

u******y

The manufacture of EcoPura auto label machine is based on the production technology, which is an international leading level. Its painting color can be customized to satisfy the needs of different customers

a******r

EcoPura auto label machine is produced from design to production which is under exquisite management. It has an anti-abrasion spraying coat, which improves its long term abrasion performance

m******y

Shenzhen EcoPura Water Equipment Co.,Ltd According to the actual development needs of the enterprise, an effective cost control system has been established. Not only has a reasonable budget been formulated for each link of product production, but also adhere to regular monitoring and inspection of the production status of the product, and timely correction of problems found. The production cost is fundamentally controlled, so that the produced Bottle Labeling Machine has a more prominent price advantage compared with similar products.
