Product Detail

Shrinking Wrapper SWP45

The system is equipped frequency-controlled speed conveyor with bottle sorting lane, film guiding system, wrapping, shrinking tunnel, Operability thanks to a user friendly human machine interface (HMI) , 100% automated from product infeed all the way down to the tunnel outfeed is synchronized with the PLC control system.Used for Water,Juice,tea,wine, beer etc other containers post packaging.

EcoPura dedicated service shrinking wrapping machine personalized for wholesale-1

EcoPura dedicated service shrinking wrapping machine personalized for wholesale-2

EcoPura dedicated service shrinking wrapping machine personalized for wholesale-3

EcoPura dedicated service shrinking wrapping machine personalized for wholesale-4

Product Parameter

Model	SWP45
Packing Speed	40-45Pack/min
Packing Standard	23,33,34,44,45,46bottles/pack
PLC & Touch Screen	Siemens
Air Cylinder	Airtac
Sensor and relay	Omron, SMC
Assembled Size	1200015602600mm
Wrapper Part Size	320015602600mm
Shrink Tunnel Size	400013001840mm
Conveyor	48001080920mm (height adjustable)
Sealing & Cutting time	0.5-1s
Working Air pressure	0.6-0.8Mpa
Weight	5500kgs
Total Power	60kw

Features

♦ 1. Touch screen with friendly interface convenient for man-machine communication and operation
♦ 2. With automatic functions of bottles feeding and sorting, wrapping, sealing shrinking, cooling and shaping. can handle different packing combination
♦ 3. The quick seal cooling function ensure the package with a higher strength even in high speed production condition.
♦ 4. The inductive switch controls the film feeding system to reliably adjust and control film feeding length with less loss
♦ 5. Unique centrifugal thermal air circulation system that has an equal heat distribution ensuring outstanding and durable shrinkage shape.

x******s

It can be configured in a straight line or in an L-shaped configuration Advantages such as shrinking wrapping machine have helped shrinking wrapping machine win the market.

w******w

The production of shrink wrapper for sale always takes shrink wrapper for sale into account. The product is equipped with air conveyor and frequency control

t******j

shrink wrapper for sale adopt shrink wrapper for sale materials, generate features such as shrink wrapper for sale. The product has the advantage of low failure rate

t******r

The shrinking wrapping machine material of shrink wrapper for sale makes it a shrinking wrapping machine. It has a robust design, supported by an aluminum plate

h******w

For its material, we used shrinking wrapping machine that was typical for shrink wrapper for sale. The product features a high degree of automation

c******f

Shenzhen EcoPura Water Equipment Co.,Ltd Reduce the cost of material procurement by establishing an efficient, fast, and affordable one-stop raw material procurement model, and then use automated production equipment for product production, thereby saving labor costs and making the produced shrink wrapper for sale high quality and low price , can save more procurement costs for wholesale customers.
