Well-chosen in material, fine in workmanship, excellent in quality and favorable in price, EcoPura Water Treatment Equipment & Bottling Machine's water treatment equipment is highly competitive in the domestic and foreign markets.EcoPura Water Treatment Equipment & Bottling Machine's water treatment equipment has been substantially improved in a scientific way, as shown in the following aspects.

Product Details

With a focus on details, EcoPura Water Treatment Equipment & Bottling Machine strives to create high-quality bottling line.EcoPura Water Treatment Equipment & Bottling Machine provides diversified choices for customers. bottling line is available in a wide range of types and styles, in good quality and in reasonable price.

Company Advantages
1. EcoPura bottle filling machine manufacturers is scientifically designed. Basic knowledge such as Mechanics of Machines, Mechanics of Materials, Fluid Mechanics, Thermodynamics is used in its manufacture.
2. drink filling machine can stand all kinds of strict tests before putting into use.
3. The growth of EcoPura also needs the efforts of customer service team.
4. If any non-humanized malfunction for our drink filling machine, Shenzhen EcoPura Water Equipment Co.,Ltd will repair for free or arrange replacement.

Product Detail

ECOPURA 3-in-1 PET 0.3L-1.5L DHSG-series monobloc equipped with isobaric filler nozzles designated for filling carbonated beverages such as Cola, beer, carbonated water and other liquids etc

EcoPura csd drink filling machine factory for upgrade industries-1

Product Specification

Model	Bottle Spec	Capacity Cal@500ML	Power	PLC & HMI
DHSG16-12-6	0.33L-1.5L Height:150-330mm Dia: 50-115mm	3000-3500bph	1.8kw	SIEMENS
DHSG24-16-6		4000-5000bph	2.2kw
DHSG24-18-8		5000-6000bph	2.2kw
DHSG24-24-8		8000-9000bph	3.0kw
DHSG32-32-12		10000-12000bph	5.5kw
DHSG38-38-14		12000-15000bph	7.5kw
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

EcoPura csd drink filling machine factory for upgrade industries-2

High quality & Strict Hygiene

Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316. hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination. The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

EcoPura csd drink filling machine factory for upgrade industries-3

EcoPura csd drink filling machine factory for upgrade industries-4

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene.The PET container is first pressed on by the PET lifting unit and pressurised afterwards. Once the same pressure is in the ring bowl and the PET container, the filling valve will be opened and the filling process starts. The liquid is gently fed via a swirl insert into the bottle. Two different filling speeds guarantee optimum flow behaviour. A flow meter monitors the fed liquid quantity. Once the exact filling volume has been reached, the flow meter provides a signal and the valve closes electro pneumatically Maximum flexibility − Filling of non-carbonated and carbonated products on one system Maximum filling accuracy − Precise determination of fill quantity via inductive flow meter Gentle product treatment during filling − Low-foam and low-turbulence filling vias wirl insert in the valve Hygiene and stable filling processes − Separate gas channels for pressurization and snifting ECOPURA filling machines in their standard version are suitable for CIP and beverage mixer

Capping Part

The capper is most precise part ensuring the machine to run credibility and product quality. The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish. As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutch ends the capping process. All main parts made of stainless steel AISI304 Pick station with adjustable height Torque and spring force of the capping head are adjustable Flushable cap retainer Motorised height adjustment of the capper top part with bottle selection feature

EcoPura csd drink filling machine factory for upgrade industries-5

EcoPura csd drink filling machine factory for upgrade industries-6

Caps online Sterilization

ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

Company Features
1. Shenzhen EcoPura Water Equipment Co.,Ltd is invested by lots of money and equipped with many talents.
2. Our high-technology drink filling machine is the best.
3. Shenzhen EcoPura Water Equipment Co.,Ltd has a leading industry position and brand. Check now! EcoPura values the work that can add value for customers. Check now! Shenzhen EcoPura Water Equipment Co.,Ltd intends to enter the international marketplace by supplying exquisite soft drink filling machine and exceptional service. Check now! Shenzhen EcoPura Water Equipment Co.,Ltd is a company that always insists on customer first. Check now!

u******a

The design of EcoPura soft drink filling machine involves several factors. These factors include part tolerances, size limitations, materials selection, mechanical analysis, function realization, etc. Logo and company nameplate can be made on the product

o******t

The workmanship of EcoPura drink filling machine requires particular skills of machinists. It has to be welded, stamped, and brazed by professional workers, and its parts are put together and fastened by hands during assembly. It is fully compatible with PC software for easy setup and data logging

t******l

EcoPura drink filling machine is manufactured in line with industrial standards. Its plug, electric cords, and socket are made complying with the local electricity supply system.

f******y

EcoPura soft drink filling machine is manufactured by taking an array of regulatory compliance into considerations, including electrical safety, electromagnetic compatibility (EMC) and the chemical composition of materials. It can be installed either horizontally or vertically with a variety of optional end-fittings

o******o

EcoPura drink filling machine meets electrical international standards. They generally include IEC 60038 (IEC standard voltages) and IEC60076 (Power transformers). Adopting titanium as one of the materials, it features high strength and stable chemical properties

m******w

This product has certain air permeability. It provides a tunnel for the skin to exchange air with the outside world. In the meantime, it contributes to the divergence of human heat. This product has certain air permeability. It provides a tunnel for the skin to exchange air with the outside world. In the meantime, it contributes to the divergence of human heat. The product provides a fast response time
