Shrinking Wrapper SWP20

The system is equipped frequency-controlled speed conveyor with bottle sorting lane, film guiding system, wrapping, shrinking tunnel, Operability thanks to a user friendly human machine interface (HMI) , 100% automated from product infeed all the way down to the tunnel outfeed is synchronized with the PLC control system.Used for Water,Juice,tea,wine, beer etc other containers post packaging.

EcoPura carton shrink wrap equipment personalized for wholesale-1

EcoPura carton shrink wrap equipment personalized for wholesale-2

EcoPura carton shrink wrap equipment personalized for wholesale-3

EcoPura carton shrink wrap equipment personalized for wholesale-4

Product Parameter

Model	SWP20
Packing Speed	18-20Pack/min
Packing Standard	23,33,34,44,45,46bottles/pack
PLC & Touch Screen	Siemens
Air Cylinder	Airtac
Sensor and relay	Omron, SMC
Assembled Size	1200010002100mm
Wrapper Part Size	320011002100mm
Shrink Tunnel Size	400010001840mm
Conveyor	48001080920mm (height adjustable)
Sealing & Cutting time	0.5-1s
Working Air pressure	0.6-0.8Mpa
Weight	2500kgs
Total Power	30kw

Features

♦ 1. Touch screen with friendly interface convenient for man-machine communication and operation
♦ 2. With automatic functions of bottles feeding and sorting, wrapping, sealing shrinking, cooling and shaping. can handle different packing combination
♦ 3. The quick seal cooling function ensure the package with a higher strength even in high speed production condition.
♦ 4. The inductive switch controls the film feeding system to reliably adjust and control film feeding length with less loss
♦ 5. Unique centrifugal thermal air circulation system that has an equal heat distribution ensuring outstanding and durable shrinkage shape.

t******e

The design of EcoPura automatic shrink wrap machine is strictly conducted. It is carried out by our designers who think highly of parts and components safety, the whole machine safety, operation safety, and environmental safety.

a******q

Before delivery, EcoPura automatic shrink wrap machine has to undergo a wide range of tests. It is strictly tested in terms of the strength of its materials, statics&dynamics performance, resistance to vibrations&fatigue, etc.

b******v

EcoPura automatic shrink wrap machine is strictly assessed after production. Many factors include part tolerances, size limitations, materials properties, mechanical analysis, and function realization have been analyzed.

k******v

The design of EcoPura automatic shrink wrap machine involves many considerations. They may include stress points, support points, yield points, wear resistance capacity, toughness, and friction force.

t******c

EcoPura automatic shrink wrap machine has gone through some important production stages. They cover the preparation of raw materials, parts machining, plating and anodizing, assembly, and testing.

k******c

The product produced under the circumstances we set meets the strictest quality criteria.
