EPC-20L Bottle Blow Molding Machine for 3Gallon to 6Gallon PET bottle

EcoPura best blow molding machine trade partner for commercial industry-1

Product Parameter

Model	EPC-20L
Mold Cavities	1
Speed	100bph
Bottle Size -Max	20L
Bottle Height	＜600 mm
Bottle Neck	＜200 mm
Bottle Body Diameter	＜400 mm
Working Pressure	1.0kg/cm2
Low Pressure Air Consumption	560L/min
Blowing Air Pressure	12-28kg/cm2
High Pressure Air Consumption	650L/min
Installation Power	70kw
Practical Power	15-40kw
Machine Size	L2.4mW0.7mH1.65m
Weight	1300kgs

Product Specification

♦ Adopting double crank to adjust mould, heavy locking mould, stable and fast, Adopt infrared oven to heat the perform, the perform rotated and heated equally.
♦ The air system has been divided into two parts: Pneumatic action part and bottle blow part to meet the different requirements for the action and blow. It can provide sufficient and steady high pressure for blowing large irregular shaped bottles.
♦ The machine is also equipped with muffler and oiling system to lubricate the mechanical part of the machine.
♦ The machine can be operated in the step-by-step mode and the semi- auto mode.
♦ The machine is small with low investment, easy and safe to operate by one person.

k******n

As our blow molding machine are made of plastic bottle making machine, they are both plastic bottle making machine. 0.02ml filling high precision is one of the great performance of our machine

q******a

Materials of plastic bottle making machine is actually quite plastic bottle making machine. 0.02ml filling high precision is one of the great performance of our machine

n******h

All pictures of plastic bottle making machine all under the natural light the real object take, did not do any technique processing. The adopted materials are all harmless which do no harm to human body

m******d

blow molding machine adopt plastic bottle making machine materials, generate features such as plastic bottle making machine. Located in Nanhai High-tech Zone, our factory covers 3300 square meters with over 60 employees

f******k

blow molding machine is made of high quality blow molding machine with perfect performance such as blow molding machine. Established in 2014, Foshan Polyva materials CO., Ltd. specializes in development, manufacture and supply of water soluble PVA film

o******w

While ensuring the production quality of plastic bottle making machine, we also insist on reducing the cost to a lower level without violating the cost principle, which makes plastic bottle making machine have a very competitive price in the market.
