automatic drink filling machine 3in1 wholesale for upgrade industries

Application Scope

water treatment equipment produced by EcoPura Water Treatment Equipment & Bottling Machine is mostly used in the following aspects.EcoPura Water Treatment Equipment & Bottling Machine has been engaged in the production of water treatment equipment for many years and has accumulated rich industry experience. We have the ability to provide comprehensive and quality solutions according to actual situations and needs of different customers.

Enterprise Strength

EcoPura Water Treatment Equipment & Bottling Machine pays attention to product quality and service. We have a specific customer service department to provide comprehensive and thoughtful services. We can provide the latest product information and solve customers' problems.

Company Advantages
1. Before delivery, EcoPura soda filling machine has to undergo a wide range of tests. It is strictly tested in terms of the strength of its materials, statics&dynamics performance, resistance to vibrations&fatigue, etc.
2. drink filling machine presents the characteristics with soda filling machine .
3. Heavy tasks are now done with the help of this product. It produces more work with little energy and also within a limited time.
4. The product is vital for many industries. It plays an important role in increasing productivity and cutting labor costs for manufacturers.

Product Detail

ECOPURA 3-in-1 PET 0.3L-1.5L DHSG-series monobloc equipped with isobaric filler nozzles designated for filling carbonated beverages such as Cola, beer, carbonated water and other liquids etc

EcoPura automatic drink filling machine wholesale for upgrade industries-1

Product Specification

Model	Bottle Spec	Capacity Cal@500ML	Power	PLC & HMI
DHSG16-12-6	0.33L-1.5L Height:150-330mm Dia: 50-115mm	3000-3500bph	1.8kw	SIEMENS
DHSG24-16-6		4000-5000bph	2.2kw
DHSG24-18-8		5000-6000bph	2.2kw
DHSG24-24-8		8000-9000bph	3.0kw
DHSG32-32-12		10000-12000bph	5.5kw
DHSG38-38-14		12000-15000bph	7.5kw
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

EcoPura automatic drink filling machine wholesale for upgrade industries-2

High quality & Strict Hygiene

Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316. hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination. The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

EcoPura automatic drink filling machine wholesale for upgrade industries-3

EcoPura automatic drink filling machine wholesale for upgrade industries-4

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene.The PET container is first pressed on by the PET lifting unit and pressurised afterwards. Once the same pressure is in the ring bowl and the PET container, the filling valve will be opened and the filling process starts. The liquid is gently fed via a swirl insert into the bottle. Two different filling speeds guarantee optimum flow behaviour. A flow meter monitors the fed liquid quantity. Once the exact filling volume has been reached, the flow meter provides a signal and the valve closes electro pneumatically Maximum flexibility − Filling of non-carbonated and carbonated products on one system Maximum filling accuracy − Precise determination of fill quantity via inductive flow meter Gentle product treatment during filling − Low-foam and low-turbulence filling vias wirl insert in the valve Hygiene and stable filling processes − Separate gas channels for pressurization and snifting ECOPURA filling machines in their standard version are suitable for CIP and beverage mixer

Capping Part

The capper is most precise part ensuring the machine to run credibility and product quality. The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish. As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutch ends the capping process. All main parts made of stainless steel AISI304 Pick station with adjustable height Torque and spring force of the capping head are adjustable Flushable cap retainer Motorised height adjustment of the capper top part with bottle selection feature

EcoPura automatic drink filling machine wholesale for upgrade industries-5

EcoPura automatic drink filling machine wholesale for upgrade industries-6

Caps online Sterilization

ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

Company Features
1. Through professional management methods, EcoPura has played a key role in the process of drink filling machine industry.
2. We have a plant that is perfect in scale, precision, and speed. Being well equipped, it helps us to have the unrivalled manufacturing capacity, so we can offer unbeatable delivery times.
3. Customer satisfaction is the highest goal of Shenzhen EcoPura Water Equipment Co.,Ltd. Inquire online! Shenzhen EcoPura Water Equipment Co.,Ltd has made full preparation to meet up with all victories or challenges. Inquire online! EcoPura endeavors to be one of the few professional carbonated soft drinks filling machine supplier with its own R&D ability. Inquire online!

v******i

EcoPura soda filling machine has passed through a comprehensive range of quality control tests to make sure it is totally free of hazardous substances.

w******c

The fabric of EcoPura drink filling machine is carefully chosen by our designers on the basis of fashion trends, quality, performance, and suitability.

b******n

The entire production process of EcoPura soda filling machine is tightly controlled, from selecting the finest fabrics to processing them into finished clothing.

x******z

The fabrics of EcoPura soda filling machine has passed through the stretch test and it is proven to be qualified for proper elasticity.

s******j

EcoPura soda filling machine has been tested on dimensional stability, performance(abrasion or pilling), and colorfastness to meet the regulatory requirements of the apparel industry.

x******k

This product can last for decades. Its joints combine the use of joinery, glue, and screws, which are tightly combined with each other.
