standard bottle blowing machine 6el wholesale for commercial industry

Company Advantages
1. EcoPura bottle blowing machine is designed using the optimum quality material and modern techniques. The product features a high degree of automation
2. The product can foster a safe environment as it does all the work without an operator having to be present. The product can enhance the speed, accuracy, and efficiency of workers
3. This product has such features as lightweight, high compressive strength and load-carrying capacity. And it is strong enough to bear rough handling. Made of stainless steel materials, the product has a smooth surface to resist dust and dirt

Product Detail

EPC-20L Bottle Blow Molding Machine for 3Gallon to 6Gallon PET bottle

EcoPura 6el bottle blowing machine wholesale for commercial industry-1

Product Parameter

Model	EPC-20L
Mold Cavities	1
Speed	100bph
Bottle Size -Max	20L
Bottle Height	＜600 mm
Bottle Neck	＜200 mm
Bottle Body Diameter	＜400 mm
Working Pressure	1.0kg/cm2
Low Pressure Air Consumption	560L/min
Blowing Air Pressure	12-28kg/cm2
High Pressure Air Consumption	650L/min
Installation Power	70kw
Practical Power	15-40kw
Machine Size	L2.4mW0.7mH1.65m
Weight	1300kgs

Product Specification

♦ Adopting double crank to adjust mould, heavy locking mould, stable and fast, Adopt infrared oven to heat the perform, the perform rotated and heated equally.
♦ The air system has been divided into two parts: Pneumatic action part and bottle blow part to meet the different requirements for the action and blow. It can provide sufficient and steady high pressure for blowing large irregular shaped bottles.
♦ The machine is also equipped with muffler and oiling system to lubricate the mechanical part of the machine.
♦ The machine can be operated in the step-by-step mode and the semi- auto mode.
♦ The machine is small with low investment, easy and safe to operate by one person.

Company Features
1. Shenzhen EcoPura Water Equipment Co.,Ltd primarily manufactures a wide range of bottle blowing machine to meet customer's various needs.
2. More customers speak highly of the quality of blow molding machine manufacturer made by EcoPura.
3. Our environmental sustainability strategy is about reducing our own environmental impacts against ambitious targets, building business resilience against climate change and supporting our clients with their sustainability challenges. Call!

o******a

The production technology of EcoPura blow molding machine manufacturer is comparatively mature in the industry. It is available in standard and heavy duty versions

d******z

Made of high-quality materials and manufactured using advanced technology, EcoPura bottle blow molding machine shows the finest workmanship in the industry. It easily resists shock loads and torsional forces normally incurred by the bulldozer

j******i

blow molding machine manufacturer is well equipped and ensures longer functional life.

f******u

EcoPura bottle blow molding machine is made of high-quality materials selected from reliable and internationally-certified suppliers. It is less prone to crack and deform

q******j

EcoPura bottle blow molding machine shows the outstanding performance, after years of improvement in the production process. The production process is managed in an efficient manner and therefore this product is produced at a quick rate. Being heat treated and annealed during the manufacturing process, it has a stable dimension

u******n

bottle blow molding machine Guide rails, reels, door curtains and other structures meet the standards, and have high hardness and precision. After professional processing, the finished product not only has excellent fireproof, moisture-proof, and windproof functions, but also has stable lifting, fast speed, and more worry-free and labor-saving operation. .
