low cost juice filling machine 4in1 international market for trader

Application Scope

EcoPura Water Treatment Equipment & Bottling Machine's bottle filling machine is widely used in various scenes.EcoPura Water Treatment Equipment & Bottling Machine always provides customers with reasonable and efficient one-stop solutions based on the professional attitude.

Company Advantages
1. EcoPura juice filling machine is designed and crafted as we firmly follow international standards.
2. The product is guaranteed to be of consistent quality with the adoption of the statistical quality control technique.
3. This product is the customer's first choice product, the service life is long, the practicality is strong.
4. Shenzhen EcoPura Water Equipment Co.,Ltd has a wholly-owned sales subsidiary in many regions in China.
5. Shenzhen EcoPura Water Equipment Co.,Ltd fully understand the customer's sensitive points and pain points.

Product Detail

ECOPURA 4-in-1 PET 0.3L-1.5L RHSG-series Hot-fill monobloc equipped with electronic filler nozzles designated for filling hot beverages such as Juice ,tea,pulp beverages or those liquid mixed particles

EcoPura 4in1 juice filling machine international market for trader-1

Product Specification

Model	Bottle Spec	Capacity Cal@500ML	Power	PLC & HMI
RHSG24-24-16-6	0.33L-1.5L Height:150-330mm Dia: 50-115mm	5000-6000bph	2.2kw	SIEMENS
RHSG24-24-18-8		7000-8000bph	2.2kw
RHSG24-24-24-8		10000-12000bph	2.0kw
RHSG32-32-32-12		15000-18000bph	5.5kw
RHSG38-38-38-14		18000-20000bph	7.5kw
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

Why 4-in-1 ?
Twin bottle rinsing station include chemical water rinsing and Ozonated water rinsing ensuring the performance with strict hygiene standard

EcoPura 4in1 juice filling machine international market for trader-2

High quality & Strict Hygiene

Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Chemical Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination .The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

EcoPura 4in1 juice filling machine international market for trader-3

EcoPura 4in1 juice filling machine international market for trader-4

Ozonated Water Washing Part

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene. Neck-handling grippers position the PET container beneath the filling valve. Once the container has been centred, the filling process starts: Thereby, the Filling valve is opened and the product flows into the bottle with infinitely variable speed. Once the required fill volume has been reached, the flow meter provides a signal to the filling valve. The valve is now closed and the filling process completed. Dripping of the filling valve is prevented by a sieve in the product discharge. Microbiological safety by filling in a multi-chamber mode and separate return gas channel Precise determination of fill quantity via inductive flow meter Recirculation channel for heat retention of the product Perfect flow characteristics through two filling speeds Cleaning in a closed system using automatically positioned CIP cups

EcoPura 4in1 juice filling machine international market for trader-5

EcoPura 4in1 juice filling machine international market for trader-6

Capping Part

The capper is most precise part ensuring the machine to run credibility and product quality.The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish.As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutch ends the capping process. All main parts made of stainless steel AISI304 Pick station with adjustable height Torque and spring force of the capping head are adjustable Flushable cap retainer Motorised height adjustment of the capper top part with bottle selection feature

Caps online Sterilization

ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

EcoPura 4in1 juice filling machine international market for trader-7

Company Features
1. Shenzhen EcoPura Water Equipment Co.,Ltd is a juice filling machine service provider for many well-known companies and development companies.
2. The cutting-edge technology adopted in juice bottling machine helps us win more and more customers.
3. The goal of Shenzhen EcoPura Water Equipment Co.,Ltd is to build a brand name through excellent quality and mature after-sales service. Ask! Our company is striving hard to become the most competitive and strong supplier with global influence by making an effort in product strategy. Ask! The company always do marketing based on ethical standards. The company will not try to manipulate or falsely advertise to its customers or potential consumers. Ask! High-quality product with zero defect is the goal we pursue. We encourage employees especially the production team to carry out strict quality inspection, from the incoming materials to the final products.

n******b

juice bottling machine The workmanship is fine, the materials are exquisite, the design is scientific, the structure is reasonable, and before leaving the factory, there will be special quality inspection personnel to test, so the quality is guaranteed.

u******v

The company has always adhered to fine management for many years, and strictly controls the quality of every important link such as product design, research and development, production, testing, and delivery to ensure that the juice bottle filling machine produced are all qualified products that meet national standards.

e******l

juice bottling machine From raw material selection, production to processing, there are professionals to conduct testing. Not only that, juice bottling machine After the production is completed, it will be inspected by relevant national departments to ensure that it meets international standards and is of high quality. , high-quality products of excellent quality.

p******u

After years of industry exploration, Shenzhen EcoPura Water Equipment Co.,Ltd has not only accumulated rich production experience, but also mastered advanced production technology, which can realize juice bottling machine good and fast production, and all juice bottling machine have undergone strict quality inspections and meet national standards Quality inspection standards, quality is trustworthy.

i******t

Shenzhen EcoPura Water Equipment Co.,Ltd There is a product research and development department with professional design talents. The structural design of each part of juice filling machine is more independent and creative. The designed product has a novel appearance and is equipped with exquisite workmanship. Carved and portrayed carefully in both places and as a whole, the final finished product is of high quality and extraordinary quality.

c******f

This product is ensured with optimum quality and durability. The product can withstand the fluctuations of large voltage
