high quality juice bottling machine 4in1 international market for distribution

Company Advantages
1. EcoPura juice bottling machine is developed according to the basic law of the construction of machines, including the drive system, operate and control system, and the supporting device working principle. The product is equipped with a high-efficiency operation system
2. This product has become a necessity in many industries. It brings immeasurable economic benefits by increasing labor productivity and controlling costs. Its overload protection function can effectively protect operators from harm
3. The product has overload protection. It has a thermal relay which can withstand the impact of short circuit due to thermal inertia. The product can ensure a high filtration rate
4. This product attracts attention with its excellent heat dissipation performance. With built-in latest cooling system, it has sufficient airflow for long-term work. The product is hygiene with no bacteria or mold built up
5. The product is stable in operation. During its operation, it is not easily affected by external factors such as sudden vibrations and shocks. The product is widely used for commercial applications

Product Detail

ECOPURA 4-in-1 PET 0.3L-1.5L RHSG-series Hot-fill monobloc equipped with electronic filler nozzles designated for filling hot beverages such as Juice ,tea,pulp beverages or those liquid mixed particles

EcoPura 4in1 juice bottling machine international market for distribution-1

Product Specification

Model	Bottle Spec	Capacity Cal@500ML	Power	PLC & HMI
RHSG24-24-16-6	0.33L-1.5L Height:150-330mm Dia: 50-115mm	5000-6000bph	2.2kw	SIEMENS
RHSG24-24-18-8		7000-8000bph	2.2kw
RHSG24-24-24-8		10000-12000bph	2.0kw
RHSG32-32-32-12		15000-18000bph	5.5kw
RHSG38-38-38-14		18000-20000bph	7.5kw
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

Why 4-in-1 ?
Twin bottle rinsing station include chemical water rinsing and Ozonated water rinsing ensuring the performance with strict hygiene standard

EcoPura 4in1 juice bottling machine international market for distribution-2

High quality & Strict Hygiene

Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Chemical Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination .The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

EcoPura 4in1 juice bottling machine international market for distribution-3

EcoPura 4in1 juice bottling machine international market for distribution-4

Ozonated Water Washing Part

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene. Neck-handling grippers position the PET container beneath the filling valve. Once the container has been centred, the filling process starts: Thereby, the Filling valve is opened and the product flows into the bottle with infinitely variable speed. Once the required fill volume has been reached, the flow meter provides a signal to the filling valve. The valve is now closed and the filling process completed. Dripping of the filling valve is prevented by a sieve in the product discharge. Microbiological safety by filling in a multi-chamber mode and separate return gas channel Precise determination of fill quantity via inductive flow meter Recirculation channel for heat retention of the product Perfect flow characteristics through two filling speeds Cleaning in a closed system using automatically positioned CIP cups

EcoPura 4in1 juice bottling machine international market for distribution-5

EcoPura 4in1 juice bottling machine international market for distribution-6

Capping Part

The capper is most precise part ensuring the machine to run credibility and product quality.The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish.As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutch ends the capping process. All main parts made of stainless steel AISI304 Pick station with adjustable height Torque and spring force of the capping head are adjustable Flushable cap retainer Motorised height adjustment of the capper top part with bottle selection feature

Caps online Sterilization

ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

EcoPura 4in1 juice bottling machine international market for distribution-7

Company Features
1. Shenzhen EcoPura Water Equipment Co.,Ltd has evolved into an experienced Chinese manufacturer. In the past years, we are engaged in the development, design, and production of tea filling machine.
2. Shenzhen EcoPura Water Equipment Co.,Ltd is highly professional in terms of its advanced technology.
3. EcoPura brand will further develop service quality. Please contact.

t******h

EcoPura tea filling machine is under the real-time control of the R&D team. The team will carry out a routine sampling and analysis of the raw materials so as to acquire information necessary for the economic appraisal of ores and concentrates.

g******y

EcoPura tea filling machine is produced under advanced equipment. It will be processed by fastness to washing tester, steamer and washer, as well as vacuum cleaning equipment designed for textile.

g******y

EcoPura juice bottling machine is under constant control in terms of health, safety, and environmental protection standards, as evidenced by the CE certificate issued.

e******w

The quality control of EcoPura juice bottling machine is conducted rigorously. It is tested in terms of its air circulation, surface treatment, as well as the most important part, thermal dissipation performance.

m******t

All EcoPura tea filling machine are manufactured in compliance with rubber and plastic industry standards and are tested for quality conformance in the laboratory.

e******v

The product features stable performance. The proportions of the various raw materials are carefully mixed together to achieve consistent properties.
