standard water process equipment 40000lh solution expert for water purification

Company Advantages
1. Being unique in its water treatment plant process , the water process equipment manufactured by EcoPura is very popular among customers. Adopting an intelligent circuit design, the product has a self-check function
2. Shenzhen EcoPura Water Equipment Co.,Ltd has its own factory, which enables us to strictly control quality. The product is equipped with air conveyor and frequency control
3. A number of quality tests will be carried out to ensure that products meet industry quality standards. The product has the advantage of low failure rate
4. This product is durable and well received by users. The product is able to provide a great purifying effect
5. Products are tested by our quality experts in strict accordance with a series of parameters to ensure the quality and performance. It can be configured in a straight line or in an L-shaped configuration

Product Detail

Commercial seawater reverse osmosis desalination system

ECOPUR manufactures a full line of sea water desalination systems designed for heavy-duty or continuous service in marine applications on and off shore.

EcoPura 40000lh water process equipment solution expert for water purification-1

EcoPura 40000lh water process equipment solution expert for water purification-2

EcoPura 40000lh water process equipment solution expert for water purification-3

Compact & Durable

EcoPura Seawater Reverse Osmosis Systems feature a unique and innovative compact design that allows for easy installation in any size area. The high-grade corrosion resistant powder coated frame features a modular design that allows for the system to be divided into multiple assemblies for easier mounting. The commercial SWRO Series is also equipped with premium components which include duplex SS centrifugal-type high pressure pump for high performance and corrosion resistance, a programmable computer controller with many built-in features, 1000 psi fiberglass membrane housings for durability and special seawater membranes for high quality product water.

Commercial SWRO Series Capacity

Our commercial SWRO Series is available with capacities ranging from 380 GPD to 10,000 GPD and a maximum feed water TDS of 42,000 ppm. We offer standard SWRO Series units as well as customizable to fit you water application needs. Whether it's for your luxury yacht, cruise line, or for a five-star resort on the beach, EcoPura has the right desalination system for you project.

EcoPura 40000lh water process equipment solution expert for water purification-4

EcoPura 40000lh water process equipment solution expert for water purification-5

Customizable For Your Needs

When your needs demand continuous-duty, commercial-grade water making, the solution is very clear. The EcoPura SWRO Series is efficient and extremely reliable. These water makers systems deliver great volumes of potable fresh water with capacities ranging between 380 to 10,000 GPD. Ideal for commercial vessels, island homes, oil platforms, hotels, or large yachts. SWC commercial water makers will provide wherever clean, pure, fresh water is needed. Employing our advanced microprocessor control panel, SWC commercial reverse osmosis unit enables advanced, total control and user-friendly system customization.

Product Specification

Operation Specifications

Max. feed water temperature: 42°C

Equipment upgrade for TDS up to 50,000 ppm

H2S, turbidity and organics must be removed

Feed water TDS: 10,000-42,000 ppm

Operating pressure: 700 to 1,000 ps

pH tolerance range: 3-11

Feed water pressure: 40 to 80 psi

Antiscalant dosing is required

Max. Iron content: 0.05 ppm

Model	Capacity		Membranes
Model	GPD	M3/D	Size	Qty
SWRO380	380	1.4	2.5" x 40"	1
SWRO700	700	2.7	2.5" x 40"	2
SWRO1000	1000	3.8	2.5" x 40"	3
SWRO2000	2000	8	4" x 40"	2
SWRO3000	3000	11	4" x 40"	3
SWRO3800	3800	14	4" x 40"	4
SWRO4700	4700	18	4" x 40"	5
SWRO5600	5600	21	4" x 40"	6
SWRO6000	6000	23	4" x 40"	7
SWRO7600	7600	29	4" x 40"	8
SWRO10000	10000	38	4" x 40"	10

Operation Specifications

Available Options

Powder coated steel frame

Heavy duty 5 micron cartridge prefilter

Sea water resistant SS pump

Microprocessor/PLC based control panel & VFD

Glycerin-filled 316 SS prefilter pressure gauges

Product & reject flow meters

TFC spiral wound membranes

FRP membrane housings

380V/3Ph/50Hz power supply

Low & high pressure switches

Permeate TDS monitor

Stainless steel high pressure piping

Stainless steel throttling valve for reject stream

Automatic feed shut off valve

Energy recovery on 64K GPD and larger

Booster pump

380-415V/3Ph/50Hz power supply

Product tank level switch

pH controller with sensor

ORP controller with sensor

Hour meter

Cleaning skid

50 micron bag filter for open intake

Carbon prefilter

Multimedia prefilter

UV sterilizer

Custom designed units

Export crating

Chemical dosing units

The ideal applications for an Industrial Sea Water RO system include

Oil Tankers

Island-Based Businesses

Villages & Cities

Cargo Ships

Coastal Developments

Hotels & Resorts

Seaside Work Sites

Work Boats

Fish Processing Plants

Seaside Villas

Company Features
1. By integrating water treatment plant process and ro water plant , EcoPura has enough confidence to offer water process equipment with high quality and affordable price. We have a robust technical development team with strong technical competency and system integration capabilities. Such a team enables us to provide customers with diverse customized product solutions that cater to different cost and precision requirements.
2. With successively developed hundreds of series of products, our company has won a large number of customers. We will strengthen its cooperations with overseas enterprises to enlarge its international business.
3. Because of our high quality standards and reliable delivery schedules, we have been able to build and maintain a solid customer base around the world. Putting water treatment products first is always our tenet. Contact us!

z******e

EcoPura water process equipment is finely processed by using well-selected materials and the advanced production techniques.

m******y

EcoPura ro water plant is exquisitely designed from a group of innovative designers.

v******k

By using the finest materials, advanced production method, the workmanship of EcoPura ro water plant is at a cutting-edge of the industry.

c******k

EcoPura water treatment products has a user-friendly design featuring both functionality and aesthetics.

v******e

EcoPura ro water plant is strictly manufactured in line with the production procedure.

x******m

water treatment products Exquisite material selection, excellent workmanship, stable structure, safe use, strong and durable, has the advantages of anti-wear and pressure resistance, corrosion resistance, strong bearing capacity, etc., and is not easy to be damaged or deformed even if it is used for a long time.
