Company Advantages1. EcoPura juice filling machine is strictly assessed after production. Many factors include part tolerances, size limitations, materials properties, mechanical analysis, and function realization have been analyzed.
2. The product is highly efficient in heat dissipation. With its powerful cooling system, it can maintain a proper working temperature.
3. The product is not prone to deformation caused by large temperature difference. Its heavy-duty components and parts are designed to withstand great abuse in changing environments.
4. There is a multitude of benefits when manufacturers use this product to upgrade production, such as increased productivity and lowered labor costs.
5. The use of this product can deepen the operator's understanding of machine operation and promote the accumulation of technical knowledge, which is an important role in machine operation.
ECOPURA 3-in-1 PET 0.3L-1.5L RHSG-series Hot-fill monobloc equipped with electronic filler nozzles designated for filling hot beverages such as Juice ,tea,pulp beverages or those liquid mixed particles
Model |
Bottle Spec |
Capacity Cal@500ML | Power | PLC & HMI |
DHSG16-16-12-6 | 0.33L-1.5L
Height:150-330mm
Dia: 50-115mm |
3000-3500bph |
1.8kw | SIEMENS |
DHSG24-24-16-6 | 4000-5000bph | 2.2kw |
DHSG24-24-18-8 | 5000-6000bph | 2.2kw |
DHSG24-24-8 | 8000-9000bph | 3.0kw |
DHSG32-32-32-12 | 10000-12000bph | 5.5kw |
DHSG38-38-38-14 | 12000-15000bph | 7.5kw |
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us. |
High quality & Strict Hygiene
Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components
The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination. The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.
Filling Part
Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene.Neck-handling grippers position the PET container beneath the filling valve. Once the container has been centred, the filling process starts: Thereby, the Filling valve is opened and the product flows into the bottle with infinitely variable speed. Once the required fill volume has been reached, the flow meter provides a signal to the filling valve. The valve is now closed and the filling process completed. Dripping of the filling valve is prevented by a sieve in the product discharge. Microbiological safety by filling in a multi-chamber mode and separate return gas channel Precise determination of fill quantity via inductive flow meter Recirculation channel for heat retention of the product Perfect flow characteristics through two filling speeds Cleaning in a closed system using automatically positioned CIP cups
Capping Part
The capper is most precise part ensuring the machine to run credibility and product quality.The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish. As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutch ends the capping process. All main parts made of stainless steel AISI304 Pick station with adjustable height Torque and spring force of the capping head are adjustable Flushable cap retainer Motorised height adjustment of the capper top part with bottle selection feature
Caps online Sterilization
ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing
It is widely popular that EcoPura brand now leads the juice filling machine industry.
2. We have largely broadened our overseas markets. In recent years, the sales statistics show that the sales volume in the markets has doubled and estimates to continue to grow.
3. Our mission is to help customers create amazing products that attract the attention of their customers. Whatever the customer does, we are ready, willing and able to help them differentiate their products in the market. This is what we do for every customer. Inquiry! We have stepped up seriously into practicing sustainable development. We have strived to reduce waste and carbon footprint during production, and we also recycle packaging materials for reuse. We have made a commitment to continuously improve all processes within the organization; always looking for a quicker, safer, better, easier, cleaner, simpler way of doing things. Inquiry! We work with our clients to help them tackle their environmental and social challenges and in doing so promote the transition to more sustainable market economies.
