low cost juice bottling machine 3in1 more buying choices for distribution

Application Scope

bottling line has a wide range of applications. It is mainly used in the following industries and fields.EcoPura Water Treatment Equipment & Bottling Machine has professional engineers and technicians, so we are able to provide one-stop and comprehensive solutions for customers.

Product Comparison

EcoPura Water Treatment Equipment & Bottling Machine has great production capability and excellent technology. We also have comprehensive production and quality inspection equipment. bottling line has fine workmanship, high quality, reasonable price, good appearance, and great practicality.bottling line's outstanding advantages are as follows.

Company Advantages
1. EcoPura juice bottling machine is manufactured in mechanical rooms that are dedicated to mechanical equipment. It will go through stamping, CNC machining, and surface treating such as coating and lacquering.
2. The product has the advantage of stable mechanical properties. Having been treated under extremely cold temperatures, its mechanical components are tensile enough to withstand extreme industrial conditions.
3. The product operates stably and reliably. It can withstand running fatigue and is not easily affected by temperature and pressure.
4. By using this product, business owners will less likely to witness workplace accidents and workman’s compensation claims.

Product Detail

ECOPURA 3-in-1 PET 0.3L-1.5L RHSG-series Hot-fill monobloc equipped with electronic filler nozzles designated for filling hot beverages such as Juice ,tea,pulp beverages or those liquid mixed particles

EcoPura 3in1 juice bottling machine more buying choices for distribution-1

Product Specification

Model	Bottle Spec	Capacity Cal@500ML	Power	PLC & HMI
DHSG16-16-12-6	0.33L-1.5L Height:150-330mm Dia: 50-115mm	3000-3500bph	1.8kw	SIEMENS
DHSG24-24-16-6		4000-5000bph	2.2kw
DHSG24-24-18-8		5000-6000bph	2.2kw
DHSG24-24-8		8000-9000bph	3.0kw
DHSG32-32-32-12		10000-12000bph	5.5kw
DHSG38-38-38-14		12000-15000bph	7.5kw
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

EcoPura 3in1 juice bottling machine more buying choices for distribution-2

High quality & Strict Hygiene

Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination. The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

EcoPura 3in1 juice bottling machine more buying choices for distribution-3

EcoPura 3in1 juice bottling machine more buying choices for distribution-4

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene.Neck-handling grippers position the PET container beneath the filling valve. Once the container has been centred, the filling process starts: Thereby, the Filling valve is opened and the product flows into the bottle with infinitely variable speed. Once the required fill volume has been reached, the flow meter provides a signal to the filling valve. The valve is now closed and the filling process completed. Dripping of the filling valve is prevented by a sieve in the product discharge. Microbiological safety by filling in a multi-chamber mode and separate return gas channel Precise determination of fill quantity via inductive flow meter Recirculation channel for heat retention of the product Perfect flow characteristics through two filling speeds Cleaning in a closed system using automatically positioned CIP cups

Capping Part

The capper is most precise part ensuring the machine to run credibility and product quality.The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish. As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutch ends the capping process. All main parts made of stainless steel AISI304 Pick station with adjustable height Torque and spring force of the capping head are adjustable Flushable cap retainer Motorised height adjustment of the capper top part with bottle selection feature

EcoPura 3in1 juice bottling machine more buying choices for distribution-5

EcoPura 3in1 juice bottling machine more buying choices for distribution-6

Caps online Sterilization

ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

Company Features
1. Shenzhen EcoPura Water Equipment Co.,Ltd has manufactured a wide collection of quality bottling juice equipment . We have evolved and grown dramatically in recent years.
2. Over the years, we have built up a strong customer base that is loyal to us for years. The long-term cooperation with those customers promotes to achieve a win-win situation.
3. Shenzhen EcoPura Water Equipment Co.,Ltd will keep improving and striving for best juice bottling machine . Get price! The build of a corporate core value system of juice filling equipment drives EcoPura to grow. Get price! Shenzhen EcoPura Water Equipment Co.,Ltd can provide customization and sending samples service for all customers. Get price! EcoPura seeks sustainable development, and actively undertake social responsibility to promote juice filling machine price . Get price!

z******m

The design of EcoPura juice bottling machine involves several factors. These factors include part tolerances, size limitations, materials selection, mechanical analysis, function realization, etc. It is made based on the national explosion-proof standard

m******u

The workmanship of EcoPura juice filling equipment requires particular skills of machinists. It has to be welded, stamped, and brazed by professional workers, and its parts are put together and fastened by hands during assembly. The product provides a fast response time

o******z

EcoPura juice bottling machine is manufactured in line with industrial standards. Its plug, electric cords, and socket are made complying with the local electricity supply system. Customized catalogs and brochures related to the product are available

u******k

EcoPura juice filling machine price is manufactured by taking an array of regulatory compliance into considerations, including electrical safety, electromagnetic compatibility (EMC) and the chemical composition of materials. Adopting titanium as one of the materials, it features high strength and stable chemical properties

j******g

EcoPura juice filling machine price meets electrical international standards. They generally include IEC 60038 (IEC standard voltages) and IEC60076 (Power transformers). Customized catalogs and brochures related to the product are available

k******v

This product has certain air permeability. It provides a tunnel for the skin to exchange air with the outside world. In the meantime, it contributes to the divergence of human heat. This product has certain air permeability. It provides a tunnel for the skin to exchange air with the outside world. In the meantime, it contributes to the divergence of human heat. Customized catalogs and brochures related to the product are available
