100% quality water bottle filling machine 3l10l producer for sale

Product Comparison

EcoPura Water Treatment Equipment & Bottling Machine has professional production workshops and great production technology. bottle filling machine we produce, in line with the national quality inspection standards, has reasonable structure, stable performance, good safety, and high reliability. It is also available in a wide range of types and specifications. Customers' diverse needs can be fully fulfilled.EcoPura Water Treatment Equipment & Bottling Machine's bottle filling machine is produced in strict accordance with standards. We make ensure that the products have more advantages over similar products in the following aspects.

Company Advantages
1. To cater to the concept of green, EcoPura fill line adopts eco-friendly materials.
2. Efficient heat transfer is one of its biggest selling points. The materials' thermal conductivity is high and has relations to their heat dissipation efficiency.
3. The product is anti-rust. All of its metal parts have been treated with anodization, hence, it is not easily get rust or corroded.
4. The product has an ever-increasing level of technology and automation to reduce the number of unskilled workers required in the production process.
5. This product promotes a clear distribution of responsibilities. Operators with specific roles are able to complete their assigned tasks more efficiently.

Product Detail

ECOPURA 3-in-1 PET 3L-10L HSG-series monobloc equipped with overflow filler nozzles designated for filling non-carbonated beverages such as pure or mineral, still water and other liquids etc

EcoPura 100% quality water bottle filling machine producer for sale-1

Product Parameter

Model	Bottle Spec	Capacity Cal@5L	Power	PLC & HMI
HSG10-10-5	3L-10L	1200-1500bph	2.2kw	SIEMENS
HSG12-12-5		1500-2000bph	3.0kw
HSG14-14-5		2000-2500bph	4.0kw
HSG16-16-5		2500-3000bph	5.5kw
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

EcoPura 100% quality water bottle filling machine producer for sale-2

High quality & Strict Hygiene

Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination
The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

EcoPura 100% quality water bottle filling machine producer for sale-3

EcoPura 100% quality water bottle filling machine producer for sale-4

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene.
Bottom-holding position the PET container beneath the filling valve. Once the container has been centred, the filling process starts: Thereby, the Filling valve is opened and the product flows into the bottle with infinitely variable speed. Once the required fill volume has been reached, the flow meter provides a signal to the filling valve. The valve is now closed and the filling process completed. Dripping of the filling valve is prevented by a sieve in the product discharge.
Microbiological safety -Contact-free filling and optimized machine design
High filling accuracy -Use of flow meters and infinitely variable flow speeds
High availability -Top efficiency thanks to the combination with ECOPURA cap feed systems
ECOPURA standard Machines are suitable for CIP

Capping Part

The capper is most precise part ensuring the machine to run credibility and product quality.The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish. As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutchends the capping process. All main parts made of stainless steel AISI304 . Pick station with adjustable height Torque and spring force of the capping head are adjustable . Flushable cap retainer . Motorised height adjustment of the capper top part with bottle selection feature

EcoPura 100% quality water bottle filling machine producer for sale-5

EcoPura 100% quality water bottle filling machine producer for sale-6

Caps online Sterilization

ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

Company Features
1. Together with the massive benefit of high capacity, Shenzhen EcoPura Water Equipment Co.,Ltd is enlarging its manufacturing scale to satisfy the higher requirements for water bottle filling machine .
2. We are proud to own many innovative engineers and elites. They aim at the core value of innovation and lean production, which enables them to offer creative and dependable products for customers from worldwide.
3. It is extremely important to Shenzhen EcoPura Water Equipment Co.,Ltd that our customers are not only satisfied with our products but also our service. Get more info! Shenzhen EcoPura Water Equipment Co.,Ltd would like to build long-term cooperation relationships with you. Get more info!

o******e

Shenzhen EcoPura Water Equipment Co.,Ltd has a modern factory building, and introduces advanced water bottle filling machine production equipment, and water bottle filling machine after the production is completed, it will be tested by the relevant national departments to meet the national quality standards, ensuring that it not only has high output, but also stable performance and high quality .

k******b

Shenzhen EcoPura Water Equipment Co.,Ltd After years of careful management, a set of scientific and rigorous production process has been established, and the quality is strictly controlled in all aspects of product design, production, quality inspection, and delivery. The water bottle filling machine produced is fine in workmanship and high in quality , Strong practicability.

l******w

fill line The workmanship is fine, the materials are exquisite, the design is scientific, the structure is reasonable, and before leaving the factory, there will be special quality inspection personnel to test, so the quality is guaranteed.

m******u

We pay great attention to product quality, adhere to the introduction of scientific production concepts, adopt professional production equipment and use advanced production technology to manufacturewater bottle filling machine, and have established a complete set of quality inspection procedures to strictly test each batch of products leaving the factory to ensure that all Products are in line with national quality inspection standards.

e******d

water bottle filling machine Carefully designed by professional designers, the design is scientific and reasonable, and selected high-quality raw materials are processed with advanced technology to make it of excellent quality and more durable.

v******p

This product is able to achieve maximum light output in a matter of seconds. being arranged in an orderly manner, its bulb can work simultaneously and provide full brightness in one second. It makes passenger's takeoff smooth and easy
